PARKER HANNIFIN part description

Parker’s MV series valves allow extremely close control of fluids used in actuating and governing equipment. The needle allows fine adjustment at low flow by using the first three turns of the adjusting knob. The next three turns open the valve to full flow, and provides standard throttling adjustment.

Markets:
• Factory Automation
• Machine Tools
• Marine
• Material Handling
• Mining
• Miscellaneous Industrial
• Miscellaneous Manufacturing
• Molding
• Oil &Gas
• Power Generation
• Vehicle Assembly Facilities

Features/Benefits:
• Port options include NPT and SAE
• Material offerings are brass and steel
• Available in an in-line or right angle style
• Port sizes are available in 7 sizes from 1/8” to 1”
• MVK mounting kits make panel mounting simple
• High efficiency o-ring stem seal eliminates packing
• Fine and micro-fine needles available for extremely fine control
• The exclusive “Colorflow” color-band provide an accurate visual indication of setting

Applications:
• Suitable for general hydraulic applications

Specifications

Style Metering Valve
Maximum Flow (lpm) 95
Maximum Flow (gpm) 25
Maximum Operating Pressure (psi) 6000
Maximum Operating Pressure (bar) 413
Maximum Operating Temperature (F) +250°
Minimum Operating Temperature (F) -40°
Maximum Operating Temperature (C) -40°
Minimum Operating Temperature (C) +121°
Brand Colorflow
Media Oil

Parker Hannifin® is a global leader in motion and control technologies. Included in the world's Fortune 250 companies, Park Hannifin's products are vital not only to automobiles but also to almost everything that moves or needs control. These include all forms of transportation, manufacturing and processing raw materials, as well as infrastructure development and construction. Established in 1918, the Parker Appliance Company's evolution into Parker Hannifin Corporation demonstrates a legacy of innovation and Parker's tradition of excellence. Parker Hannifin's product portfolio includes solenoid valves, hydraulic fittings, pressure relief valves, hydraulic pumps, polyurethane tubing, thermal and power management products, and other parts for climate control, hydraulics, filtration, fluid and gas handling, pneumatics, sealing and shielding, and many other applications.
