(888) 312-8812 Login SignupHORTON 79A8110 CLUTCH*DMA2S SE 24*REMAN,CUM,12-PK,184.6,126.95 PLT,26.6 STUDS
Tap to view 2 more
MSRP: $2,444.55
$1,31199
Save $1,132.56
+$533.33 core deposit
Total price w/ core: $1,845.32
In Stock
Get it by Wednesday, Feb 18
HORTON 79A8110 Part Description
Manufacturer
Product Description
Engine Cooling Fan Clutch
Application Summary
KENWORTH
Features & Benefits
- Built to the same specifications as Horton Genuine models
- Easy-to-install, exact drop-in replacements
- Total cost can be less than rebuilding
- Two-year warranty for line-haul applications
- Credit for old Horton or competitor cores
- Low eddy-current speeds reduce noise, increase available horsepower, conserve fuel and minimize radiator abrasion
- Higher, spring-actuated fan speeds make sure necessary cooling is delivered
- Faster engine warm-ups in cold weather
- Premium bearings and friction liners
- High torque for turning large fans
- Lower parts count for easy installation and maintenance
Two-speed fan clutch, fan clutch, engine cooling, fan drive, performance, cooling system, horsepower, performance, reman
HORTON 79A8110 Specifications
Product Attributes
| BACK PULLEY DIAMETER | 7.31 IN |
| BELT CONFIGURATION | 12PK |
| Belt Groove Location | 6.66 IN |
| BOLT CIRCLE | 6 IN |
| Center of JB To Top Right Mounting Hole | 1.81 IN |
| Fan Blade Stud Length | 1.05 IN |
| FAN PILOT DIAMETER | 5 IN |
| Heavy Duty | 1 |
| HORIZONTAL MOUNTING DISTANCE | 6.36 IN |
| Overall Length | 12.67 IN |
| Stud Thread Size | .312-18 UNC IN |
| VERTICAL MOUNTING DISTANCE | 1.81 IN |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8483604040 |
| Harmonized Tariff Code (HTS) | 8483604040 |
| NAFTA Preference Criterion Code | B |
| OEM's Part Number | 98A8110 |
| Warranty Distance | 300000 |
| Warranty Distance UOM | DH |
| Warranty Special | 7500 Hours |
| Warranty Special UOM | TX |
| Warranty Time | 36 |
| Warranty Time UOM | MO |
| VMRS Code | 042003131 |
HORTON 79A8110 Cross References
| Brand | Part Number |
|---|---|
| 98A8110 | |
| Freightliner | HOR 79A8110 |
| Horton | 98A8110, 99A8110, K798110, P99A8110, R798110 |
| KENWORTH | F17-6017M28 |
| KIT MASTERS | 99595-2 |
| Mack | 3912-79A8110 |
| NAVISTAR | FLT995952 |
| NAVISTARPFC | FLT995952 |
| Navistar | HOR79A8110, ZBH79A8110 |
| Paccar Parts | 79A8110RMAN |
| Peterbilt | F17-6017M28 |
