(888) 312-8812 Login SignupWABCO 9254861010 Air Brake Spring Brake Cylinder Assembly - Tristop-Cylinder Disc G-12/16
Tap to view 3 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
WABCO 9254861010 Part Description
WABCO 9254861010 Specifications
Product Attributes
| Distance between bolts | 120.6 mm |
| Push-Rod Length | 15 mm |
| Max. operating pressure | 10.2/8.5 bar |
| Max. operating pressure | 147.94 / 123.28 psi |
| Weight | 15.73 |
| Type | 12/16 |
| Calculated Volume (dm³) | 14.0813 |
| Return-Spring Force | 150 N |
| Total Length | 252.0 mm |
| Size | 380 x 192 x 193 |
| Temperature Range | -40°C to +80°C |
| Bolt Lengths | 43.0 mm |
| Push-rod thread | Ball R8 |
| Output Force M | 5760 N |
| Port threads | M22 x 1.5 VOSS 232 |
| Stroke | 57/57 mm |
| Type Of Operation | Disc |
| Bolt Threads | M16 x 1.5 |
| Release Pressure | 5.1 bar |
| Port thread 12 | M22 x 1.5 JED - 388 |
| Port thread 11 | M22 x 1.5 JED - 388 |
WABCO 9254861010 Cross References
| Brand | Part Number |
|---|---|
| MERCEDES-BENZ | 0214200118 |
WABCO 9254861010 Customer Reviews
No reviews yet
Be the first to review this product!
WABCO 9254861010 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
