(888) 312-8812 Login SignupWABCO 9121120010 Air Brake Compressor - Single Cylinder 318cc, Flange Mounted
Tap to view 3 more
$1,35399
14 Day Lead Time
Due to limited availability, we will confirm your order and notify you within 1 business day.
WABCO 9121120010 Part Description
WABCO 9121120010 Specifications
Product Attributes
| Calculated Volume (dm³) | 18.8811 |
| Piston stroke | 2.20 in |
| Size | 343 x 311 x 177 |
| Weight | 35.5782 |
| Swept Volume (Cm³) | 318 cm3 |
| Max. operating pressure | 203.1 psi |
| Type Of Operation | High pressure using unloader |
| Piston Diameter | 3.35 in |
| Port Thread 9 | M16 x 1.5 |
| Port Thread 0 | Ø 34.9 mm |
| Operating speed | 3000 (1/min) |
| Port Thread 9.2 | M16 x 1.5 |
| Crankshaft thread | M20 x 1.5 |
| Port Thread 8.1 | M12 x 1.5 |
| Lubrication | Lubrication supplied from engine |
| Port thread 4 | M16 x 1.5 |
| Port Thread 9.1 | M16 x 1.5 |
| Port thread 2 | M26 x 1.5 |
| Type | Single Cylinder |
| Cooling | Water |
WABCO 9121120010 Cross References
We have 3 alternatives for the 9121120010 by WABCO:
WABCO 9121120010 Customer Reviews
No reviews yet
Be the first to review this product!
WABCO 9121120010 Manufacturer Information
Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
