DELPHI part description

Product Description

Ignition Coil

Product Attributes

Notes PV8 Fully Integrated System has 4 Coils and 1 Module. Cassette color is Black
Interface Description 6 Pin Sealed Connector, 4 HV Terminals, & Ground Spring
Package Contents Ignition Coil, Complete Assembly
Position(s) Right
Ignition Type Electronic
Coil Type Plug Top Coil (PTC)
Coil Wire Included No
Oil Filled No
Requires External Resistor No
Terminal Type Blade
Mounting Hardware Included No
Wire Quantity 0
Grade Type Regular
Mount Type 8 Mounting Holes
Mounting Hole Quantity 8
Terminal Quantity 7
Connector Gender Female
Terminal Gender Male
Voltage 12.0 2H
Maximum Diameter 0.484 IN
Length 17 IN
Width 6.43 IN
Height 3.55 IN
Maximum Diameter 12.3 MM
Length 432 MM
Width 163.3 MM
Height 90.1 MM

Additional Information

Warranty Distance UOM DH
Warranty Distance 36000
Harmonized Tariff Code (Schedule B) 8511300080
Harmonized Tariff Code (HTS) 8511300080
Warranty Time UOM MO
Warranty Time 36
Country of Origin (Primary) CN
UPC 00689604125663
VMRS Code 033003001
UNSPSC 26101769

Part Interchanges

Fits Vehicles

  • Oldsmobile Aurora (2001-2003)
  • Cadillac Seville (2000-2003)
  • Cadillac Eldorado (2000-2002)
  • Cadillac DeVille (2000-2003)
