Delphi FG0809 - Fuel Pump Module Assembly
$39199
MSRP: $564.04
Save: $172.05
In stock
limited availability at this price!
Pay over 3-12 months with . Learn more
DELPHI part description
Product Description
Fuel Pump Module Assembly
Product Attributes
System Pressure | 55 psi |
Vapor Pressure Sensor | Yes |
Fuel Level Sender Assembly Included | Yes |
Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Instruction Sheet |
Item Grade | Standard Replacement |
Outlet Outside Diameter | 0.375 IN |
Voltage | 12 2H |
Fuel Type | Gas |
Regulator Included | Yes |
Maximum Pressure | 80 PS |
Terminal Type | Blade |
Gasket Or Seal Included | Yes |
Terminal Quantity | 4 |
Lock Ring Included | No |
Terminal Gender | Male |
Strainer Included | Yes |
Inlet Type | Strainer |
Outlet Type | Quick Connect |
Outlet Quantity | 3 |
In Tank or External | In Tank |
Resistance Ohms Empty | 250 82 |
Resistance Ohms Full | 40 82 |
Internal Or External Strainer | Internal |
Pump Type | Electric |
Average Current Draw | 9 68 |
Average Flow Rating | 30 GPH |
Fuel Sending Unit Included | Yes |
Negative Ground | No |
Mounting Hardware Included | No |
Grade Type | Premium |
Connector Quantity | 1 |
Connector Shape | Oval |
Housing Material | Plastic |
Installation Warnings | No |
Connector Gender | Female |
Fuel Filter Included | Yes |
Gasket Or Seal Material | Nitrile Rubber |
Minimum Pressure | 55 PS |
Wire Harness Included | No |
Pump Design | Turbine |
Fuel Tank Pressure Sensor Included | Yes |
Additional Information
Harmonized Tariff Code (Schedule B) | 8413309000 |
Harmonized Tariff Code (HTS) | 8413309030 |
Warranty Special | Limited Lifetime |
Warranty Special UOM | LF |
Country of Origin (Primary) | TH |
UPC | 00689604197943 |
VMRS Code | 044003258 |
UNSPSC | 25172409 |
Part Interchanges
- General Motors 19168774
- General Motors 19207718
- General Motors 19256622
- General Motors 88965555
- ACDelco 19168774
- ACDelco MU1657
- Magneti Marelli 1AMFP00104
- Carter P76272M
- Airtex E3610M
- Spectra Premium SP6026M
- Bosch 67567
- ACDelco TS1016
- Carquest M2520851
- AutoZone DFG0809
- General Motors 19370396
- General Motors 88965386
- EVO Driveline AFS0957S
- EVO Driveline RE0957S
- Precision Fuel A40001
- USEP3610M
- F2621A
- D0236M
Fits Vehicles
- Cadillac Escalade EXT (2004-2007)
- Cadillac Escalade ESV (2004-2007)
- Chevrolet Avalanche (2007)
- GMC Yukon XL 1500 (2004-2007)
- Chevrolet Suburban 1500 (2004-2007)
- Chevrolet Avalanche 1500 (2004-2006)
