Delphi FG0085 - Fuel Pump Module Assembly
$30199
MSRP: $441.40
Save: $139.41
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Fuel Pump Module Assembly
Product Attributes
| Vapor Pressure Sensor | No |
| System Pressure | 62 psi |
| Fuel Level Sender Assembly Included | Yes |
| Package Contents | Fuel Pump Module Assembly w/Float Arm, Seal, Splices, Wire Harness, Instruction Sheet |
| Item Grade | Standard Replacement |
| Outlet Outside Diameter | 0.375 IN |
| Voltage | 13 2H |
| Fuel Type | Gas |
| Regulator Included | No |
| Maximum Pressure | 109 PS |
| Terminal Type | Blade |
| Gasket Or Seal Included | Yes |
| Terminal Quantity | 4 |
| Lock Ring Included | No |
| Terminal Gender | Male |
| Strainer Included | Yes |
| Inlet Type | Strainer |
| Outlet Type | Quick Connect |
| Outlet Quantity | 3 |
| In Tank or External | In Tank |
| Resistance Ohms Empty | 40 82 |
| Resistance Ohms Full | 250 82 |
| Internal Or External Strainer | External |
| Pump Type | Electric |
| Average Current Draw | 10 68 |
| Average Flow Rating | 32 GPH |
| Fuel Sending Unit Included | Yes |
| Negative Ground | No |
| Mounting Hardware Included | No |
| Wire Quantity | 4 |
| Grade Type | Premium |
| Connector Quantity | 1 |
| Connector Shape | Oval |
| Housing Material | Plastic |
| Installation Warnings | No |
| Connector Gender | Female |
| Fuel Filter Included | No |
| Gasket Or Seal Material | Nitrile Rubber |
| Minimum Pressure | 62 PS |
| Wire Harness Included | Yes |
| Pump Design | Turbine |
| Fuel Tank Pressure Sensor Included | No |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8413309000 |
| Harmonized Tariff Code (HTS) | 8413309030 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TH |
| UPC | 00689604060223 |
| VMRS Code | 044003258 |
| UNSPSC | 25172409 |
Part Interchanges
- General Motors 19177240
- General Motors 25314319
- 9535042
- ACDelco MU1282
- ACDelco MU145
- ACDelco MU1752
- Magneti Marelli 1AMFP00187
- EVO Driveline AFS0442S
- EVO Driveline RE0442S
- Carter P74768M
- P74898M
- P74934M
- Airtex E3962M
- Spectra Premium SP6145M
- E3962M
- Bosch 67381
- DENSO Auto Parts 953-0025
- DENSO Auto Parts 953-5042
- Carquest M3246782
- AutoZone EFG0085
- General Motors 19331271
- General Motors 19369941
- Dorman 2630331
- Precision Fuel A30042
- MasterPro Fuel Pumps MPA30042
- TruGrade D5331027
- USEP3962M
- F2973A
- C0358M
DELPHI FG0085 Cross Reference
We have 2 alternatives for the FG0085 by DELPHI:
Fits Vehicles
- GMC C3500HD (1998-1999)
- Chevrolet C3500HD (1998-1999)
- GMC K3500 (1998-2000)
- GMC K2500 (1998-2000)
- GMC C3500 (1998-2000)
- GMC C2500 (1998-2000)
- Chevrolet K3500 (1998-2000)
- Chevrolet K2500 (1998-2000)
- Chevrolet C3500 (1998-2000)
- Chevrolet C2500 (1998-2000)
