CENTRIC 123.66024 Part Description
Manufacturer
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
CENTRIC 123.66024 Specifications
Product Attributes
| Misc Holes [cntrc] | 4 |
| Weight [cntrc] Kgs | 10.909 |
| Weight [cntrc] Lbs | 24.000 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 165.100 |
| Bolt Circle Diameter [cntrc] In | 6.500 |
| Hub Hole / Register [cntrc] Mm | 116.840 |
| Hub Hole / Register [cntrc] In | 4.600 |
| Height [cntrc] Mm | 127.508 |
| Height [cntrc] In | 5.020 |
| Friction Surface Width [cntrc] Mm | 80.772 |
| Friction Surface Width [cntrc] In | 3.180 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 285.500 MM |
| Maximum Brake Diameter (Discard) | 11.240 IN |
| Bolt Hole Quantity | 8 |
| Outside Diameter | 329.946 MM |
| Outside Diameter | 12.990 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 13.462 MM |
| Mounting Hole Diameter | 0.530 IN |
| Nominal Drum Diameter | 283.200 MM |
| Nominal Drum Diameter | 11.150 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890915300 |
CENTRIC 123.66024 Cross References
CENTRIC 123.66024 Fits Vehicles
- Chevrolet C20 Panel (1967)
- GMC P25/P2500 Van (1971-1973)
- GMC C25/C2500 Suburban (1971-1972)
- GMC C25/C2500 Pickup (1967-1972)
- Chevrolet P20 Van (1971-1973)
- Chevrolet Suburban (1960-1964)
- Chevrolet C20 Suburban (1968-1972)
- Chevrolet C20 Pickup (1960-1972)
