Centric 123.67017 - C-Tek Standard Brake Drum
$6349
MSRP: $70.51
Save: $7.02
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Weight [cntrc] Kgs | 6.659 |
| Weight [cntrc] Lbs | 14.650 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Hub Hole / Register [cntrc] Mm | 72.136 |
| Hub Hole / Register [cntrc] In | 2.840 |
| Height [cntrc] Mm | 90.424 |
| Height [cntrc] In | 3.560 |
| Friction Surface Width [cntrc] Mm | 67.056 |
| Friction Surface Width [cntrc] In | 2.640 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 280.900 MM |
| Maximum Brake Diameter (Discard) | 11.060 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 320.040 MM |
| Outside Diameter | 12.600 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 15.750 MM |
| Mounting Hole Diameter | 0.620 IN |
| Nominal Drum Diameter | 279.400 MM |
| Nominal Drum Diameter | 11.000 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890915386 |
Part Interchanges
CENTRIC 123.67017 Cross Reference
We have 2 alternatives for the 123.67017 by CENTRIC:
Fits Vehicles
- Dodge W100 Pickup (1969-1974)
- Dodge W150 (1977-1978)
- Dodge W100 (1975-1977)
