Centric 123.61014 - C-Tek Standard Brake Drum
$6649
MSRP: $73.33
Save: $6.84
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Weight [cntrc] Kgs | 7.500 |
| Weight [cntrc] Lbs | 16.500 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 70.612 |
| Hub Hole / Register [cntrc] In | 2.780 |
| Height [cntrc] Mm | 87.884 |
| Height [cntrc] In | 3.460 |
| Friction Surface Width [cntrc] Mm | 59.690 |
| Friction Surface Width [cntrc] In | 2.350 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 255.500 MM |
| Maximum Brake Diameter (Discard) | 10.060 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 295.910 MM |
| Outside Diameter | 11.650 IN |
| Outer Cooling Fins | Yes |
| Mounting Hole Diameter | 13.970 MM |
| Mounting Hole Diameter | 0.550 IN |
| Nominal Drum Diameter | 254.000 MM |
| Nominal Drum Diameter | 10.000 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890914969 |
Part Interchanges
CENTRIC 123.61014 Cross Reference
We have 2 alternatives for the 123.61014 by CENTRIC:
Fits Vehicles
- Mercury Monarch (1975-1980)
- Ford Granada (1975-1980)
