Centric 123.46024 - C-Tek Standard Brake Drum
$2999
MSRP: $32.05
Save: $2.06
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Weight [cntrc] Kgs | 3.682 |
| Weight [cntrc] Lbs | 8.100 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 114.300 |
| Bolt Circle Diameter [cntrc] In | 4.500 |
| Hub Hole / Register [cntrc] Mm | 80.000 |
| Hub Hole / Register [cntrc] In | 3.150 |
| Height [cntrc] Mm | 59.500 |
| Height [cntrc] In | 2.343 |
| Friction Surface Width [cntrc] Mm | 40.300 |
| Friction Surface Width [cntrc] In | 1.587 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 205.000 MM |
| Maximum Brake Diameter (Discard) | 8.071 IN |
| Bolt Hole Quantity | 5 |
| Outside Diameter | 240.100 MM |
| Outside Diameter | 9.453 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.500 MM |
| Mounting Hole Diameter | 0.492 IN |
| Nominal Drum Diameter | 202.700 MM |
| Nominal Drum Diameter | 7.980 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890914815 |
Part Interchanges
CENTRIC 123.46024 Cross Reference
We have 1 alternatives for the 123.46024 by CENTRIC:
Fits Vehicles
- Mitsubishi Lancer (2008-2009, 2011-2016)
