*Representative image - actual part not displayed
Centric 123.42015 - C-Tek Standard Brake Drum
$3599
5 day lead time
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Drum
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Misc Holes [cntrc] | 2 |
| Weight [cntrc] Kgs | 4.886 |
| Weight [cntrc] Lbs | 10.750 |
| Mounting Type [cntrc] | Floating |
| Bolt Circle Diameter [cntrc] Mm | 100.000 |
| Bolt Circle Diameter [cntrc] In | 3.937 |
| Hub Hole / Register [cntrc] Mm | 68.000 |
| Hub Hole / Register [cntrc] In | 2.677 |
| Height [cntrc] Mm | 62.500 |
| Height [cntrc] In | 2.461 |
| Friction Surface Width [cntrc] Mm | 51.000 |
| Friction Surface Width [cntrc] In | 2.008 |
| Product Grade [cntrc] | Standard |
| Maximum Brake Diameter (Discard) | 230.000 MM |
| Maximum Brake Diameter (Discard) | 9.055 IN |
| Bolt Hole Quantity | 4 |
| Outside Diameter | 265.500 MM |
| Outside Diameter | 10.453 IN |
| Outer Cooling Fins | No |
| Mounting Hole Diameter | 12.750 MM |
| Mounting Hole Diameter | 0.502 IN |
| Nominal Drum Diameter | 228.500 MM |
| Nominal Drum Diameter | 8.996 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 805890914631 |
Part Interchanges
CENTRIC 123.42015 Cross Reference
We have 2 alternatives for the 123.42015 by CENTRIC:
Fits Vehicles
- Nissan Sentra (1987-1989)
