CENTRIC part description

Product Description

C-Tek Standard Brake Drum

Features & Benefits

  • Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket

Product Attributes

Misc Holes [cntrc] 1
Weight [cntrc] Kgs 3.182
Weight [cntrc] Lbs 7.000
Mounting Type [cntrc] Floating
Bolt Circle Diameter [cntrc] Mm 100.000
Bolt Circle Diameter [cntrc] In 3.937
Hub Hole / Register [cntrc] Mm 55.880
Hub Hole / Register [cntrc] In 2.200
Height [cntrc] Mm 56.390
Height [cntrc] In 2.220
Friction Surface Width [cntrc] Mm 39.500
Friction Surface Width [cntrc] In 1.555
Product Grade [cntrc] Standard
Maximum Brake Diameter (Discard) 201.000 MM
Maximum Brake Diameter (Discard) 7.913 IN
Bolt Hole Quantity 4
Outside Diameter 234.000 MM
Outside Diameter 9.213 IN
Outer Cooling Fins No
Mounting Hole Diameter 14.700 MM
Mounting Hole Diameter 0.579 IN
Nominal Drum Diameter 199.600 MM
Nominal Drum Diameter 7.858 IN

Additional Information

Harmonized Tariff Code (Schedule B) 8708300050
Harmonized Tariff Code (HTS) 8708305030
NAFTA Preference Criterion Code B
Country of Origin (Primary) CN
UPC 805890914594

Part Interchanges

CENTRIC 123.41003 Cross Reference

We have 2 alternatives for the 123.41003 by CENTRIC:

Fits Vehicles

  • Daihatsu Charade (1990-1992)
