Name: Stemco 309-0960 Wheel Seal - Guardian HP Seal
SKU: 3090960
Price: 54.49 USD
Availability: InStock

STEMCO part description

Product Description

Wheel Seal - Guardian HP Seal

Application Summary

9,000# Front Axle, Navistar, FA 109 Cast Wheel ’79 and up

Product Attributes

Width	0.668 IN
Seal Type	D7
Bore Diameter	6 .251 IN
INNER BEARING CONE	594A
INNER BEARING CUP	598A
INSTALL HANDLE/BODY	555-0001
OUTER BEARING CONE	HM617049
OUTER BEARING CUP	HM617010
REMARKS	GMC - Some Aluminum Hubs Use 309-0973 Seal .
SHOULDER OUTER DIAMETER	4 .767 IN
SPINDLE SHOULDER OUTER DIAMETER	4 .767 IN
TOOL HEAD	555-5071
UNIVERSAL AXLE TOOL HEAD	555-5076

Additional Information

Harmonized Tariff Code (HTS)	4205008000
UPC	00703832129986
VMRS Code	018002028

Part Interchanges

STEMCO® is a recognized global leader in manufacturing and supplying a comprehensive line of high-performance systems and components to the commercial vehicle industry. Its wide range of products includes wheel-end components, such as fasteners, hubcaps, bearings, seals, and mileage counters, and brake parts, which include brake drums, brake pads, and adjusters. It also offers suspension products like spring pins, king pin kits, polyurethane suspensions, tie rod assemblies, and mount and blocking components. All these products are made to the highest quality and safety standards to ensure superior performance and maximum durability even when used in the harshest of conditions. STEMCO is ISO-9001:2015 certified.

STEMCO 309-0960 Cross Reference

We have 59 alternatives for the 309-0960 by STEMCO:
