STEMCO part description

Product Description

Wheel Seal - Guardian HP Seal

Application Summary

12,000# Front Axle, Meritor, Eaton, Ford, Freightliner, Kenworth, Western Star, Navistar, Peterbilt, Volvo GM

Product Attributes

Width 0.76 IN
Seal Type B7
Bore Diameter 4 .542 IN
GASKET NUMBER 330-3120
HUB CAP WITH GASKET 340-4186
INNER BEARING CONE 45284
INNER BEARING CUP 45220
INSTALL HANDLE/BODY 555-0001
Notes Ford 9000# 1984 Up
OUTER BEARING CONE 3585
OUTER BEARING CUP 3525
SHOULDER OUTER DIAMETER 3 .500 IN
SPINDLE SHOULDER OUTER DIAMETER 3 .500 IN
Standard Set Equivalent 382-8063
UNIVERSAL AXLE TOOL HEAD 555-5064

Additional Information

Harmonized Tariff Code (HTS) 4205008000
UPC 00703832129870
VMRS Code 018001025

Part Interchanges

STEMCO® is a recognized global leader in manufacturing and supplying a comprehensive line of high-performance systems and components to the commercial vehicle industry. Its wide range of products includes wheel-end components, such as fasteners, hubcaps, bearings, seals, and mileage counters, and brake parts, which include brake drums, brake pads, and adjusters. It also offers suspension products like spring pins, king pin kits, polyurethane suspensions, tie rod assemblies, and mount and blocking components. All these products are made to the highest quality and safety standards to ensure superior performance and maximum durability even when used in the harshest of conditions. STEMCO is ISO-9001:2015 certified.
