Name: National Seals 9406S National 9406S Wheel Seal
SKU: 9406s
Price: 11.49 USD
Availability: InStock

NATIONAL SEALS part description

Product Description

Wheel Seal

Application Summary

1970-1983 Excalibur Phaeton (Front Inner); 1968-1969 Cadillac Commercial Chassis (Front Inner) (Qualifier: with Disc Brakes); 1968-1971 Cadillac Calais (Front Inner) (Qualifier: with Disc Brakes); 1968-1971 Cadillac DeVille (Front Inner) (Qualifier: with Disc Brakes); 1968-1971 Cadillac Fleetwood (Front Inner) (Qualifier: with Disc Brakes); 1968-1970 Chevrolet Biscayne (Front Inner) (Qualifier: with Disc Brakes); 1969-1970 Chevrolet Brookwood (Front Inner); 1969-1970 Chevrolet Kingswood (Front Inner); 1969-1970 Chevrolet Townsman (Front Inner); 1969-1970 Chevrolet Estate (Front Inner); 1968-1970 Chevrolet Bel Air (Front Inner) (Qualifier: with Disc Brakes); 1968-1970 Chevrolet Caprice (Front Inner) (Qualifier: with Disc Brakes); 1969-1982 Chevrolet Corvette (Front Inner); 1968-1970 Chevrolet Impala (Front Inner) (Qualifier: with Disc Brakes); 1968-1970 Pontiac Laurentian (Front Inner) (Qualifier: with Disc Brakes); 1968-1970 Pontiac Parisienne (Front Inner) (Qualifier: with Disc Brakes)

Features & Benefits

Design type: springless; single-lip
Temperature range: -40°F to 225°F / -40°C to 107°C
Temperature range: -40degF to 225degF / -40degC to 107degC
Good low temperature capability
Low swell in hydrocarbon fluids
Delivers quality and reliable performance for every type of repair

Product Attributes

Inside Diameter	2.000 IN
Inside Diameter	50.800 MM
Outside Diameter	2.629 IN
Outside Diameter	66.780 MM
Width	0.285 IN
Width	7.240 MM
Material	Nitrile
Housing Bore	2.625 IN
Housing Bore	66.680 MM
Part Description	Oil Seal
Series	9000
Shaft Diameter	2.000 IN
Shaft Diameter	50.800 MM
Type	279
Unit of Dimension	Inch
Grade Type	Premium

Additional Information

Country of Origin (Primary)	MX
Harmonized Tariff Code (Schedule B)	4016931020
Harmonized Tariff Code (HTS)	4016931020
Canadian Harmonizing Tariff Code	4016930000
UPC	00724956202348

Part Interchanges

Fits Vehicles

Chevrolet Estate (1969-1970)
Pontiac Parisienne (1968-1970)
Pontiac Laurentian (1968-1970)
Cadillac Commercial Chassis (1968-1969)
Excalibur Phaeton (1970-1983)
Chevrolet Townsman (1969-1970)
Chevrolet Kingswood (1969-1970)
Chevrolet Impala (1968-1970)
Chevrolet Corvette (1969-1982)
Chevrolet Caprice (1968-1970)
Chevrolet Brookwood (1969-1970)
Chevrolet Biscayne (1968-1970)
Chevrolet Bel Air (1968-1970)
Cadillac Fleetwood (1968-1971)
Cadillac DeVille (1968-1971)
Cadillac Calais (1968-1971)
