Name: National Seals 710491 National 710491 Drive Axle Shaft Seal
SKU: 710491
Price: 9.99 USD
Availability: InStock

NATIONAL SEALS part description

Product Description

Drive Axle Shaft Seal

Application Summary

1998-2000 Isuzu Hombre (Front Inner) (Drive: 4WD); 1997-2005 Chevrolet Astro (Front Inner) (Drive: AWD); 1997-2005 Chevrolet Blazer (Front Inner) (Drive: 4WD, AWD); 2003-2014 Chevrolet Express 1500 (Front Inner) (Drive: AWD); 2003-2005 Chevrolet Express 2500 (Front Inner) (Drive: AWD); 1997-2004 Chevrolet S10 (Front Inner) (Drive: 4WD); 2004-2005 GMC Envoy XUV (Front Inner) (Drive: 4WD); 2002-2006 GMC Envoy XL (Front Inner) (Drive: 4WD); 2002-2009 GMC Envoy (Front Inner) (Drive: 4WD); 2003-2014 GMC Savana 1500 (Front Inner) (Drive: AWD); 2003-2005 GMC Savana 2500 (Front Inner) (Drive: AWD); 1997-2005 GMC Jimmy (Front Inner) (Drive: 4WD); 1997-2004 GMC Sonoma (Front Inner) (Drive: 4WD); 1997-2005 GMC Safari (Front Inner) (Drive: AWD); 1997-2004 Oldsmobile Bravada (Front Inner) (Drive: AWD)

Features & Benefits

Design type: spring loaded; multi-lip
Temperature range: -20°F to 300°F / -29°C to 49°C
Temperature range: -20degF to 300degF / -29degC to 49degC
Resistance to EP lubricants
Low swell in hydrocarbon fluids
Delivers quality and reliable performance for every type of repair

Product Attributes

Inside Diameter	1.575 IN
Inside Diameter	40.000 MM
Outside Diameter	2.724 IN
Outside Diameter	69.200 MM
Width	0.610 IN
Width	15.500 MM
Material	Polyacrylate
Helix Type	Bi-Directional Lip Design
Part Description	Oil Seal
Series	710400
Shaft Diameter	1.560 IN
Shaft Diameter	39.600 MM
Thickness	0.531 IN
Thickness	13.500 MM
Type	#
Unit of Dimension	Inch
Housing Bore	2.717 IN
Housing Bore	69.000 MM
Grade Type	Premium

Additional Information

Country of Origin (Primary)	BR
Harmonized Tariff Code (Schedule B)	4016931020
Harmonized Tariff Code (HTS)	4016931020
Canadian Harmonizing Tariff Code	4016930000
UPC	00614046903227

Part Interchanges

Fits Vehicles

Isuzu Hombre (1998-2000)
GMC Envoy XL (2002-2006)
GMC Envoy XUV (2004-2005)
GMC Jimmy (1997-2005)
Oldsmobile Bravada (1997-2004)
GMC Sonoma (1997-2004)
GMC Savana 2500 (2003-2005)
GMC Savana 1500 (2003-2014)
GMC Safari (1997-2005)
GMC Envoy (2002-2009)
Chevrolet S10 (1997-2004)
Chevrolet Express 1500 (2003-2014)
Chevrolet Express 2500 (2003-2005)
Chevrolet Blazer (1997-2005)
Chevrolet Astro (1997-2005)
