NATIONAL SEALS 710247 Part Description
Manufacturer
Product Description
Multi-Purpose Seal
Application Summary
1989-2000 Isuzu Amigo (Transmission Base Gear: 5, 4 & Transmission Control Type: Manual, Automatic & Drive: 4WD / Qualifier: with Isuzu MSG-5C Transmission, with Isuzu MUA5 Transmission, with Isuzu MUA-5C Transmission, with Aisin 03-72L Transmission, with Aisin 03-75 Transmission); 1985-1989 Isuzu Impulse (Transmission Base Gear: 4 & Transmission Control Type: Automatic / Qualifier: with Aisin 03-72L Transmission, with Aisin 03-70 Transmission); 1986-1995 Isuzu Pickup (Transmission Base Gear: 5, 3, 4 & Transmission Control Type: Manual, Automatic & Drive: 4WD / Qualifier: with Isuzu MSG-5C Transmission, with Aisin 03-55 Transmission, with Aisin 03-75 Transmission, with Isuzu MUA5 Transmission, with Isuzu MUA-5C Transmission); 1991-2004 Isuzu Rodeo (Transmission Base Gear: 5 & Transmission Control Type: Manual & Drive: 4WD / Qualifier: with Isuzu MUA5 Transmission, with Isuzu MUA-5C Transmission); 2001-2003 Isuzu Rodeo Sport (Transmission Base Gear: 5 & Transmission Control Type: Manual & Drive: 4WD / Qualifier: with Isuzu MUA-5C Transmission); 1988-1997 Isuzu Trooper (Transmission Base Gear: 4 & Transmission Control Type: Automatic & Drive: 4WD / Qualifier: with Isuzu MUA TC Transfer Case, 2 Speed, with Aisin 30-80LE Transmission); 1996-1997 Acura SLX (Drive: 4WD / Qualifier: with Isuzu MUA TC Transfer Case, 2 Speed); 1994-2002 Honda Passport (Transmission Code: MUA5C & Transmission Base Gear: 5 & Transmission Control Type: Manual & Drive: 4WD / Qualifier: with Isuzu MUA TC Transfer Case, 2 Speed)
Features & Benefits
- Design type: spring loaded; single-lip
- Temperature range: -20°F to 300°F / -29°C to 49°C
- Temperature range: -20degF to 300degF / -29degC to 49degC
- Resistance to EP lubricants
- Low swell in hydrocarbon fluids
- Delivers quality and reliable performance for every type of repair
NATIONAL SEALS 710247 Specifications
Product Attributes
| Inside Diameter | 1.496 IN |
| Inside Diameter | 38.000 MM |
| Outside Diameter | 1.937 IN |
| Outside Diameter | 49.200 MM |
| Width | 0.315 IN |
| Width | 8.000 MM |
| Material | Polyacrylate |
| Helix Type | Clockwise-Spiral Lip Design |
| Part Description | Oil Seal |
| Sealing Material | Polyacrylate |
| Series | 710200 |
| Thickness | 0.315 IN |
| Thickness | 8.000 MM |
| Type | 62 |
| Unit of Dimension | Metric |
| Housing Bore | 1.929 IN |
| Housing Bore | 49.000 MM |
| Shaft Diameter | 1.496 IN |
| Shaft Diameter | 38.000 MM |
| Overall Width with Side Lip | 12.000 MM |
| Overall Width with Side Lip | 0.472 in |
| Grade Type | Premium |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 4016931020 |
| Harmonized Tariff Code (HTS) | 4016931020 |
| Canadian Harmonizing Tariff Code | 4016930000 |
| UPC | 00724956294152 |
| VMRS Code | 053019003 |
NATIONAL SEALS 710247 Cross References
| Brand | Part Number |
|---|---|
| ATP | RO-53 |
| ATP TRANSMISSION PARTS | RO-53 |
| Chicago Rawhide | 15270 |
| Honda | 8-94155-673-0, 8-94422-387-0, 8-94422-388-0, 8-97046-704-0, 8-97046-705-0, 8-97046-705-1, 8-97046-705-3 |
| Isuzu | 8-94155-673-0, 8-94422-387-0, 8-94422-388-0, 8-97046-704-0, 8-97046-705-0, 8-97046-705-1, 8-97046-705-3 |
| Payen | NJ220 |
| SKF | 15270 |
| TF VICTOR | 15270 |
| Timken | 710247 |
| TransTec | B29573 |
NATIONAL SEALS 710247 Fits Vehicles
- Isuzu Trooper (1988-1997)
- Isuzu Rodeo Sport (2001-2003)
- Isuzu Pickup (1986-1995)
- Isuzu Impulse (1985-1989)
- Isuzu Amigo (1989-1994, 1998-2000)
- Isuzu Rodeo (1991-2004)
- Honda Passport (1994-2002)
- Acura SLX (1996-1997)
