Name: National Seals 710062 National 710062 Transfer Case Input Shaft Seal
SKU: 710062
Price: 9.99 USD
Availability: InStock

NATIONAL SEALS part description

Product Description

Transfer Case Input Shaft Seal

Application Summary

1990-1998 Chevrolet Astro (Drive: AWD / Qualifier: with Borg-Warner 1372 Transfer Case, 2 Speed, with Borg-Warner 4472 Transfer Case, 1 Speed); 1991 GMC Syclone (Drive: AWD / Qualifier: with Borg-Warner 4472 Transfer Case, 1 Speed); 1992-1993 GMC Typhoon (Drive: AWD / Qualifier: with Borg-Warner 4472 Transfer Case, 1 Speed); 1990-1998 GMC Safari (Drive: AWD / Qualifier: with Borg-Warner 1372 Transfer Case, 2 Speed, with Borg-Warner 4472 Transfer Case, 1 Speed); 1991-1997 Oldsmobile Bravada (Drive: AWD / Qualifier: with Borg-Warner 1372 Transfer Case, 2 Speed, with Borg-Warner 4472 Transfer Case, 1 Speed); 1982-1990 Ford Bronco (Drive: 4WD / Qualifier: with Borg-Warner 1345 Transfer Case, 2 Speed); 1984-1990 Ford Bronco II (Drive: 4WD); 1982-1991 Ford F-150 (Drive: 4WD / Qualifier: with Borg-Warner 1345 Transfer Case, 2 Speed); 1982-1990 Ford F-250 (Drive: 4WD); 1982-1990 Ford F-350 (Drive: 4WD / Qualifier: with Borg-Warner 1345 Transfer Case, 2 Speed); 1983-1990 Ford Ranger (Drive: 4WD / Qualifier: with Borg-Warner 1350 Transfer Case, 2 Speed, with Borg-Warner 1359 Transfer Case)

Features & Benefits

Design type: spring loaded; multi-lip
Temperature range: -40°F to 225°F / -40°C to 107°C
Temperature range: -40degF to 225degF / -40degC to 107degC
Good low temperature capability
Low swell in hydrocarbon fluids
Delivers quality and reliable performance for every type of repair

Product Attributes

Inside Diameter	1.750 IN
Inside Diameter	44.450 MM
Outside Diameter	2.378 IN
Outside Diameter	60.400 MM
Width	0.484 in
Width	12.290 MM
Material	Nitrile
Part Description	Oil Seal
Sealing Material	Nitrile
Series	710000
Thickness	0.484 IN
Thickness	12.290 MM
Type	#
Unit of Dimension	Inch
Housing Bore	2.374 in
Housing Bore	60.300 MM
Shaft Diameter	1.750 IN
Shaft Diameter	44.450 MM
Seal Type	Seal
Shaft Diameter	1.750 IN
Housing Bore	2.374 IN
Grade Type	Premium

Additional Information

Country of Origin (Primary)	ID
Harmonized Tariff Code (Schedule B)	4016931020
Harmonized Tariff Code (HTS)	4016931020
Canadian Harmonizing Tariff Code	4016930000
UPC	00724956180011

Part Interchanges

Fits Vehicles

Ford Ranger (1983-1990)
Ford F-350 (1982-1990)
Ford F-250 (1982-1990)
Ford F-150 (1982-1991)
Ford Bronco II (1984-1990)
Ford Bronco (1982-1990)
Oldsmobile Bravada (1991-1994, 1996-1997)
GMC Safari (1990-1998)
GMC Typhoon (1992-1993)
GMC Syclone (1991)
Chevrolet Astro (1990-1998)
