Name: National Seals 224025 National 224025 Engine Crankshaft Seal
SKU: 224025
Price: 15.99 USD
Availability: InStock

NATIONAL SEALS part description

Product Description

Engine Crankshaft Seal

Application Summary

1986-1992 Yugo GV (Front); 1988-1989 Yugo GVL (Front); 1988 Yugo GVS (Front); 1987-1989 Yugo GVX (Front); 1990-1992 Yugo Cabrio (Front); 1984-1989 Bertone X-1/9 (Front); 1989-1994 Isuzu Amigo (Front); 1988-1989 Isuzu Impulse (Front); 1986-1995 Isuzu Pickup (Front); 1991-1997 Isuzu Rodeo (Front); 1986-1991 Isuzu Trooper (Front); 1981-1986 Chevrolet Chevette (Front); 1981-1986 Pontiac Acadian (Front); 1994-1996 Honda Passport (Front); 1966-1983 Fiat 124 (Front); 1971-1979 Fiat 128 (Front); 1975-1978 Fiat 131 (Front); 1979-1981 Fiat Brava (Front); 1979-1982 Fiat Strada (Front); 1974-1983 Fiat X-1/9 (Front); 1976 Lancia Scorpion (Front); 1976-1981 Lancia Beta (Front); 1979-1982 Lancia Zagato (Front)

Features & Benefits

Design type: spring loaded; single-lip
Temperature range: -20°F to 300°F / -29°C to 49°C
Temperature range: -20degF to 300degF / -29degC to 49degC
Resistance to EP lubricants
Low swell in hydrocarbon fluids
Delivers quality and reliable performance for every type of repair

Product Attributes

Inside Diameter	1.575 IN
Inside Diameter	40.000 MM
Outside Diameter	2.215 IN
Outside Diameter	56.250 MM
Width	0.276 IN
Width	7.000 MM
Material	Polyacrylate
Helix Type	Clockwise-Spiral Lip Design
Part Description	Oil Seal
Redicoat	Yes
Series	220000
Thickness	0.276 IN
Thickness	7.000 MM
Type	48
Unit of Dimension	Metric
Housing Bore	2.205 in
Housing Bore	56.000 MM
Shaft Diameter	1.575 IN
Shaft Diameter	40.000 MM
Shaft Diameter	1.575 IN
Housing Bore	56.000 MM
Grade Type	Premium

Additional Information

Country of Origin (Primary)	MX
Harmonized Tariff Code (Schedule B)	4016931020
Harmonized Tariff Code (HTS)	4016931020
Canadian Harmonizing Tariff Code	4016930000
UPC	00724956074976

Part Interchanges

Fits Vehicles

Chevrolet Chevette (1981-1986)
Isuzu Trooper (1986-1991)
Isuzu Rodeo (1991-1997)
Isuzu Pickup (1986-1995)
Isuzu Impulse (1988-1989)
Isuzu Amigo (1989-1994)
Bertone X-1/9 (1984-1989)
Yugo GVS (1988)
Yugo GVL (1988-1989)
Lancia Zagato (1979, 1981-1982)
Lancia Beta (1976-1979, 1981)
Fiat Strada (1979-1982)
Fiat Brava (1979-1981)
Fiat 131 (1975-1978)
Lancia Scorpion (1976)
Yugo GVX (1987-1989)
Yugo Cabrio (1990-1992)
Yugo GV (1986-1992)
Fiat X-1/9 (1974-1983)
Fiat 128 (1971-1979)
Fiat 124 (1966-1983)
Pontiac Acadian (1981-1986)
Honda Passport (1994-1996)
