Name: Moog ES140R MOOG ES140R Steering Tie Rod End
SKU: es140r
Price: 21.99 USD
Availability: InStock

MOOG part description

Passenger Car/Light Truck Applications

Make	Model	Year
BUICK	CENTURY	1958-1957
	LIMITED	1958
	ROADMASTER	1958-1957
	SPECIAL	1962-1957
	SUPER	1958-1957
DODGE	A100	1970-1964
	D100 PICKUP	1968
	D100 SERIES	1967-1961
	D200 PICKUP	1968
	D200 SERIES	1967-1961
	P200	1971-1968
JEEP	CJ3	1966-1959
	CJ5	1983-1959
	CJ5A	1968-1966
	CJ6	1975-1959
	CJ6A	1968-1966
	CJ7	1986-1976
	JEEPSTER	1973-1966
	SCRAMBLER	1985-1981
	UNIVERSAL	1967-1961
OLDSMOBILE	88	1957
	98	1959-1958
	F85	1962-1961
	JETFIRE	1962
	SUPER 88	1959-1957
PONTIAC	BONNEVILLE	1958
	CHIEFTAIN	1958-1949
	STAR CHIEF	1958-1954
	STREAMLINER	1951-1946
	SUPER CHIEF	1958-1957
	TORPEDO	1948-1946

Product Description

Steering Tie Rod End

Application Summary

1970 Fargo A108 Van (Front Right Outer); 1964-1970 Fargo A100 Van (Front Right Outer); 1966-1967 Fargo D100 Panel Delivery (Front Right Outer); 1966 Fargo D110 Pickup (Front Right Outer); 1966-1967 Fargo D200 Panel Delivery (Front Right Outer); 1968-1971 Fargo P200 Parcel Delivery (Front Right Outer); 1966-1968 Fargo D100 Pickup (Front Right Outer); 1966-1968 Fargo D200 Pickup (Front Right Outer); 1967-1970 Dodge A108 Van (Front Right Outer); 1961-1967 Dodge D100 Series (Front Right Outer); 1961-1967 Dodge D200 Series (Front Right Outer); 1964-1970 Dodge A100 Truck (Front Right Outer); 1964-1970 Dodge A100 (Front Right Outer); 1968-1971 Dodge P200 (Front Right Outer); 1968 Dodge D100 Pickup (Front Right Outer); 1968 Dodge D200 Pickup (Front Right Outer); 1961-1966 Jeep Universal (Front Right Outer, Front Left Inner, Right Outer (Steering Arm To Steering Arm)); 1963-1969 Jeep Universal Truck (Front Right Outer, Front Left Inner); 1959-1966 Jeep CJ3 (Front Right Outer, Front Left Inner); 1966-1973 Jeep Commando (Front Left Inner, Left Outer (Steering Arm To Steering Arm), Left Inner (At Bell Crank)); 1966-1971 Jeep Jeepster (Left Outer (Steering Arm To Steering Arm), Front Left Inner, Left Inner (At Bell Crank)); 1959-1983 Jeep CJ5 (Front Left Inner, Front Right Outer, Left Outer (Steering Arm To Steering Arm), At Pitman Arm, Front Left Outer); 1959-1975 Jeep CJ6 (Front Right Outer, Front Left Inner, Left Outer (Steering Arm To Steering Arm)); 1976-1986 Jeep CJ7 (Left Outer (Steering Arm To Steering Arm), Front Left Inner, At Pitman Arm, Front Left Outer); 1981-1985 Jeep Scrambler (Front Left Outer, At Pitman Arm); 1966-1968 Jeep CJ5A (Front Left Inner, Front Right Outer); 1966-1968 Jeep CJ6A (Front Right Outer, Front Left Inner); 1958 Buick Limited (Front Right Outer, Front Left Inner); 1957-1958 Buick Century (Front Right Outer, Front Left Inner); 1957-1958 Buick Roadmaster (Front Right Outer, Front Left Inner); 1957-1962 Buick...

Features & Benefits

ABSORBS IMPACT -- Belleville preload washer helps eliminate spring bind and shattering during shock load
PROBLEM SOLVER® GUSHER BEARING -- Metal-to-metal design provides strength and allows grease to flow through bearing surface for reduced friction and long life
STRONG AND DURABLE -- Ball studs are heat treated to match or exceed OE requirements to inhibit premature failure and improve fatigue strength
RESTORES LIKE-NEW STEERING -- Patented pressed-in cover plate seals out debris and minimizes looseness, reducing bearing wear and promoting longer life
GREASEABLE SOCKET -- Reduces corrosion and wear by allowing new lubricant to flush contaminants
EASY TO INSTALL -- Precision tolerances for easy installation and steering alignment giving you a perfect fit right out of the box
RIGOROUS TESTING -- Comprehensive testing throughout design and development processes by MOOG engineers for quality you can count on
COMPREHENSIVE COVERAGE -- Available for foreign and domestic nameplates

Product Attributes

End 1 Gender	MALE
End 1 Thread Diameter	0.687 IN
End 1 Thread Direction	Clockwise
End 1 Threads Per Inch	18
End 2 Gender	Male
End 2 Threads Per Inch	20
Length Stud Center to End	3.110 IN
Type	STRAIGHT
Part Description	Steering Tie Rod End

Additional Information

Country of Origin (Primary)	US
Canadian Harmonizing Tariff Code	8708949900
Harmonized Tariff Code (Schedule B)	8708948000
Harmonized Tariff Code (HTS)	8708947550
Refurbished Part	N
Remanufactured Part	N
UPC	00080066103617
VMRS Code	015004019
UNSPSC	25174205

Part Interchanges

MOOG ES140R Cross Reference

We have 1 alternatives for the ES140R by MOOG:

080066103617

Fits Vehicles

Fargo A108 Van (1970)
Fargo P200 Parcel Delivery (1968-1971)
Fargo D200 Pickup (1966-1968)
Fargo D100 Pickup (1966-1968)
Fargo D200 Panel Delivery (1966-1967)
Fargo D110 Pickup (1966)
Fargo D100 Panel Delivery (1966-1967)
Fargo A100 Van (1964-1966, 1970)
Dodge A100 (1964-1966, 1970)
Jeep Universal Truck (1963-1969)
Buick Special (1957-1958, 1961-1962)
Buick Super (1957-1958)
Jeep CJ5A (1966-1968)
Jeep CJ6A (1966-1968)
Pontiac Torpedo (1946-1948)
Pontiac Super Chief (1957-1958)
Pontiac Streamliner (1946-1951)
Pontiac Star Chief (1954-1958)
Pontiac Chieftain (1949-1958)
Pontiac Bonneville (1958)
Oldsmobile Super 88 (1957-1959)
Oldsmobile Jetfire (1962)
Oldsmobile F85 (1961-1962)
Oldsmobile Cutlass (1961-1962)
Oldsmobile 88 (1957)
Oldsmobile 98 (1958-1959)
Jeep Universal (1961-1966)
Jeep Jeepster (1966-1971)
Jeep Commando (1966-1970, 1972-1973)
Jeep CJ3 (1959-1966)
Dodge P200 (1968-1971)
Dodge D200 Series (1961-1967)
Dodge D200 Pickup (1968)
Dodge D100 Series (1961-1967)
Dodge D100 Pickup (1968)
Dodge A108 Van (1967-1970)
Dodge A100 Truck (1964-1970)
Buick Roadmaster (1957-1958)
Buick Limited (1958)
Buick Century (1957-1958)
Jeep Scrambler (1981-1985)
Jeep CJ6 (1959-1960, 1966-1975)
Jeep CJ7 (1976-1986)
Jeep CJ5 (1959-1960, 1966-1983)

For over 100 years, Moog® has been an industry leader in mid- to high-end aftermarket parts for steering, suspension, and driveline systems worldwide. Utilized by daily commuters to entire fleets, Moog parts have become synonymous with reliable performance that’s just as good or even better than their OE counterparts. Moog also incorporates innovative features in their products not found in competing products, such as patented forged steel bodies and metal “gusher” bearings that greatly reduce friction across moving components. The brand also leads the way in after-sales support, with comprehensive technical assistance and training materials available for customers around the world.
