Monroe 911181 - Reflex Suspension Shock Absorber
$5399
MSRP: $114.89
Save: $60.90
In stock
limited availability at this price!
Pay over 3-12 months with . Learn more
MONROE part description
Product Description
Reflex Suspension Shock Absorber
Features & Benefits
- IMPROVES STABILITY -- ASD (Acceleration Sensitive Damping) valving technology adjusts to impacts, reducing roll and dive for vehicles with a higher center of gravity
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger reserve tube holds more fluid to run cooler
- CONTROL AND DURABILITY -- Fluon-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- IMPROVES PERFORMANCE -- Nitrogen gas charge maintains tire-to-road contact for improved ride and handling by reducing aeration
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
Product Attributes
9791 | LS42 |
9789 | S5 |
Dust Shield Included | Yes |
9783 | No |
9908 | Yes |
9792 | No |
Part Description | Shock Absorber |
Compressed Length | 10.25 IN |
Dust Shield Material | Metal |
Extended Length | 15.125 in |
Gas Charged | Yes |
Lower Mount Type | Loop Bushing and Sleeve Mount - 14MM Sleeve ID X 1.5/16" Sleeve OAL |
Parts Pack(s) | P01167 |
Travel Length | 4.875 in |
Upper Mount Type | Stem Mount - 2.5/8" Stem Length X 1/2"-13 Thread Pitch |
Compressed Length | 260.3 MM |
Extended Length | 384.2 MM |
Travel Length | 123.8 MM |
Shock Absorber Rod End Measuring Point | Base of Stem |
Shock Absorber Body End Measuring Point | Center of Loop |
Additional Information
MSDS Sheet Number | 1164 |
Country of Origin (Primary) | US |
Canadian Harmonizing Tariff Code | 8708803000 |
Harmonized Tariff Code (Schedule B) | 8708801600 |
Harmonized Tariff Code (HTS) | 8708801600 |
UPC | 00048598841025 |
VMRS Code | 016008003 |
UNSPSC | 25172011 |
Part Interchanges
- Chevrolet 12477867
- Chevrolet 12477868
- Chevrolet 12477870
- Chevrolet 12477871
- Chevrolet 15057973
- Chevrolet 15210861
- Chevrolet 15753519
- Chevrolet 15753521
- Chevrolet 19152876
- Chevrolet 19152878
- Chevrolet 19177927
- Chevrolet 19208627
- Chevrolet 19211023
- Chevrolet 20951274
- Chevrolet 20951275
- Chevrolet 20951276
- Chevrolet 20951277
- Chevrolet 22064849
- Chevrolet 22064851
- Chevrolet 22064859
- Chevrolet 22064860
- Chevrolet 22064861
- Chevrolet 22064862
- Chevrolet 22064863
- Chevrolet 22064864
- Chevrolet 22064865
- Chevrolet 22064866
- Chevrolet 22064867
- Chevrolet 22064868
- Chevrolet 22187161
- Chevrolet 22187162
- Chevrolet 22187164
- Chevrolet 22187165
- Chevrolet 22400057
- Chevrolet 22400058
- Chevrolet 22400060
- Chevrolet 22400061
- Chevrolet 22400062
- Chevrolet 22400063
- Chevrolet 22400188
- Chevrolet 22400189
- Chevrolet 22400190
- Chevrolet 22400191
- Chevrolet 22400192
- Chevrolet 22400193
- Chevrolet 22400194
- Chevrolet 22400195
- Chevrolet 22400246
- Chevrolet 22400247
- Chevrolet 22400317
- Chevrolet 22400319
- Chevrolet 22400363
- Chevrolet 22400365
- Chevrolet 22400562
- Chevrolet 22400563
- Chevrolet 25818491
- Chevrolet 25984611
- Chevrolet 25984613
- Chevrolet 25984618
- Chevrolet 25984619
- Chevrolet 88983817
- Chevrolet 88983819
- Chevrolet 89038652
- Chevrolet 89038653
- Chevrolet 89038654
- Chevrolet 89038655
- GMC 12477867
- GMC 12477868
- GMC 12477870
- GMC 12477871
- GMC 15057973
- GMC 19152876
- GMC 19152878
- GMC 19177927
- GMC 19208627
- GMC 19211023
- GMC 20951274
- GMC 20951275
- GMC 20951276
- GMC 20951277
- GMC 22064849
- GMC 22064851
- GMC 22064859
- GMC 22064860
- GMC 22064861
- GMC 22064862
- GMC 22064863
- GMC 22064864
- GMC 22064865
- GMC 22064866
- GMC 22064867
- GMC 22064868
- GMC 22187154
- GMC 22187155
- GMC 22187159
- GMC 22187160
- GMC 22187161
- GMC 22187162
- GMC 22187164
- GMC 22187165
- GMC 22400057
- GMC 22400058
- GMC 22400060
- GMC 22400061
- GMC 22400062
- GMC 22400063
- GMC 22400188
- GMC 22400189
- GMC 22400190
- GMC 22400191
- GMC 22400192
- GMC 22400193
- GMC 22400194
- GMC 22400195
- GMC 22400246
- GMC 22400247
- GMC 22400317
- GMC 22400319
- GMC 22400363
- GMC 22400365
- GMC 22400562
- GMC 22400563
- GMC 25818491
- GMC 25984611
- GMC 25984613
- GMC 25984618
- GMC 25984619
- GMC 88983816
- GMC 88983817
- GMC 88983818
- GMC 88983819
- GMC 89038652
- GMC 89038653
- GMC 89038654
- GMC 89038655
- GMC 89060250
- Cadillac 19152876
- Cadillac 88983817
- Ultra Spring Seat G63817
- Gabriel G63817
- OEM 88983817
- Sensen 12140199
- KYB 344383
- ACDelco 560272
- ACDelco 560614
- OEM 19152876
- KYB 565102
- OEM 20951275
- OEM 19211023
- FCS Auto Parts 341598
- OEM 20951274
- OEM 19177927
- KYB KG54340
- OEM 19152878
- Rancho RS5288
- Rancho RS5295
- Rancho RS55288
- Rancho RS55295
- ACDelco 520135
- ACDelco 530311
- Chevrolet 19208003
- General Motors 19152876
- General Motors 19152878
- General Motors 19177927
- General Motors 19208003
- General Motors 19208627
- General Motors 19211023
- General Motors 20951274
- General Motors 20951275
- General Motors 88945479
- General Motors 88966866
- General Motors 88983817
- NAPA Shocks 911181
- Gold Shock Absorber 565102
- Gold Shock Absorber 9160312
- PRT 173696
- FCS 341598
- KYB KG54339
- KYB 565101
- KYB 565076
- KYB 344402
- MasterPro Shocks and Struts GM108
- Duralast TS3334721B
- NAPA Shocks NS911181
MONROE 911181 Cross Reference
We have 17 alternatives for the 911181 by MONROE:
Fits Vehicles
- GMC Sierra 1500 HD Classic (2007)
- Chevrolet Silverado 1500 HD Classic (2007)
- GMC Sierra 3500 Classic (2007)
- GMC Sierra 2500 HD Classic (2007)
- Chevrolet Silverado 3500 Classic (2007)
- Chevrolet Silverado 2500 HD Classic (2007)
- Chevrolet Silverado 3500 HD (2007-2010)
- GMC Sierra 3500 HD (2007-2010)
- GMC Yukon XL 2500 (2000-2013)
- GMC Sierra 3500 (2001-2006)
- GMC Sierra 2500 HD (2001-2010)
- GMC Sierra 2500 (1999-2004)
- GMC Sierra 1500 HD (2001-2003, 2005-2006)
- Chevrolet Suburban 2500 (2000-2013)
- Chevrolet Silverado 2500 HD (2001-2010)
- Chevrolet Silverado 3500 (2001-2010)
- Chevrolet Silverado 2500 (1999-2007)
- Chevrolet Silverado 1500 HD (2001-2003, 2005-2006)
- Chevrolet Avalanche 2500 (2002-2006)
