Monroe 66691 - Magnum Suspension Shock Absorber
$5299
MSRP: $62.08
Save: $9.09
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
MONROE part description
Product Description
Magnum Suspension Shock Absorber
Features & Benefits
- FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 3-6 trucks and buses
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while 2-in. or 2-1/4-in. reserve tube holds more fluid to improve performance (when required)
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/8-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
- BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (on most applications)
- LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration, and harshness under most driving conditions
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
- BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty
Product Attributes
| 9791 | LS53 |
| 9789 | LS41 |
| Dust Shield Included | Yes |
| 9783 | No |
| 9908 | No |
| 9792 | No |
| Part Description | Shock Absorber |
| Compressed Length | 15 IN |
| Dust Shield Material | Metal |
| Extended Length | 24 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 5/8"-16MM Sleeve ID X 2" Sleeve OAL |
| Parts Pack(s) | P01322 |
| Travel Length | 9 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 2.1/4" Sleeve OAL |
| Compressed Length | 381 MM |
| Extended Length | 609.6 MM |
| Travel Length | 228.6 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598075673 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
Part Interchanges
- Freightliner GBL65491
- Freightliner P117146
- UNITED MFG. CO. P117146
- Gabriel 83118
- OEM GBL65491
- Oshkosh P117146
- Freightliner 654918
- Oshkosh GLB654918
- Gabriel 83119
- Gabriel 83116
- FREIGHTLINER 654918
- OEM P117146
- Haldex SA66691
- Meritor M83118
- Oshkosh GBL65491
- NAPA Shocks 66691
- Automann A83118
- Gold Shock Absorber 5001312
MONROE 66691 Cross Reference
We have 13 alternatives for the 66691 by MONROE:
Fits Vehicles
- Freightliner MC Line (2001, 2005-2019)
