Monroe 66609 - Magnum Suspension Shock Absorber
$6849
3 day lead time
Pay over 3-12 months with . Learn more
MONROE part description
Product Description
Magnum Suspension Shock Absorber
Features & Benefits
- FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 3-6 trucks and buses
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while 2-in. or 2-1/4-in. reserve tube holds more fluid to improve performance (when required)
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/8-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
- BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (on most applications)
- LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration, and harshness under most driving conditions
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
- BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty
Product Attributes
9791 | S6 |
9789 | LS54 |
Dust Shield Included | Yes |
9783 | No |
9908 | No |
9792 | No |
Part Description | Shock Absorber |
Compressed Length | 13.375 IN |
Dust Shield Material | Metal |
Extended Length | 21.75 in |
Gas Charged | Yes |
Lower Mount Type | Stem Mount - 3.5/16" Stem Length X 5/8"-11 Thread Pitch |
Parts Pack(s) | P01482 |
Travel Length | 8.375 in |
Upper Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
Compressed Length | 339.7 MM |
Extended Length | 552.4 MM |
Travel Length | 212.7 MM |
Shock Absorber Rod End Measuring Point | Center of Loop |
Shock Absorber Body End Measuring Point | Base of Stem |
Additional Information
MSDS Sheet Number | 1164 |
Country of Origin (Primary) | US |
Canadian Harmonizing Tariff Code | 8708803000 |
Harmonized Tariff Code (Schedule B) | 8708801600 |
Harmonized Tariff Code (HTS) | 8708801600 |
UPC | 00048598074645 |
VMRS Code | 016008003 |
UNSPSC | 25172011 |
Part Interchanges
- Holland 90044907
- Western Star 90044907
- VOLVO / WHITE / GMC 3919571
- OEM 90044907
- Neway 57306609
- Mack 600168MT
- Monroe Vintage 660168
- Mack 600168
- Chevrolet 3919571
- Spartan B461725
- Monroe Vintage 6609
- Watson & Chalin 17218
- International AMS600168
- Gabriel 85008
- Gabriel 83635
- Monroe Vintage 600168
- General Motors 3919571
- Neway 90044907
- MACK 600168
- MACK 600168MT
- Bilstein F4B461725H0
- Haldex SA66609
- Neway 90044878
- Meritor M83635
- Monroe Shocks & Struts 600168
- Monroe Shocks & Struts 660168
- Monroe Shocks & Struts 6609
- Dayton Parts M66609
- Navistar AMS600168
- Volvo GM Heavy Truck 3919571
- NAPA Shocks 66609
- Automann A83635
- Bulldog HD HD12140644
MONROE 66609 Cross Reference
We have 22 alternatives for the 66609 by MONROE:
- MERITOR M83635
- 66609MM
- MAE66609
- GABRIEL 83635
- VOLVO / WHITE / GMC 3919571
- OEM 90044907
- NEWAY 57306609
- MACK 600168MT
- MONROE VINTAGE 660168
- MACK 600168
- CHEVROLET 3919571
- SPARTAN B461725
- MONROE VINTAGE 6609
- WESTERN STAR 90044907
- WATSON & CHALIN 17218
- INTERNATIONAL AMS600168
- GABRIEL 85008
- MONROE VINTAGE 600168
- GM 3919571
- NEWAY 90044907
- HALDEX SA66609
- BULLDOG HD SHOCKS HD1214-0644
Fits Vehicles
- Western Star 5800 (1997-2002)
- Western Star 6900 (1989-2001)
- Western Star 5900 (1989-2001)
- Western Star 4900 (1981-2002)
- Western Star 4800 (1981-2002)
- Western Star 3800 (1989-1997, 1999-2001)
