MONROE part description

Product Description

Magnum Suspension Shock Absorber

Features & Benefits

  • FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
  • BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty

Product Attributes

9791 S6
9789 LS54
Dust Shield Included Yes
9783 No
9908 No
9792 Yes
Part Description Shock Absorber
Compressed Length 15.97 IN
Dust Shield Material Metal
Extended Length 26.1 in
Gas Charged Yes
Lower Mount Type Stem Mount - 3.5/16" Stem Length X 5/8"-11 Thread Pitch
Parts Pack(s) P01482
Travel Length 10.13 in
Upper Mount Type Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL
Compressed Length 405.6 MM
Extended Length 662.9 MM
Travel Length 257.3 MM
Shock Absorber Rod End Measuring Point Center of Loop
Shock Absorber Body End Measuring Point Base of Stem

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708801600
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598173805
VMRS Code 016008003
UNSPSC 25172011

Part Interchanges

Fits Vehicles

  • Western Star 4800SF (2013-2016)
  • Western Star 4800SB (2012-2016)
  • Western Star 4900EX (2002-2016)
  • Western Star 4900FA (2002-2016)
  • Western Star 4900E (1997-2002)
  • Western Star 6900XD (2002-2016)
  • Western Star 5800 (1997-2002)
  • Western Star 4900SA (2002-2016)
  • Western Star 6900 (1995-2001)
  • Western Star 5900 (1995-2001)
  • Western Star 4900 (1995-2002)
  • Western Star 4800 (1995-2002)
  • Mack CX (1998-2005)
  • Mack CL (1991-2007)
  • Mack CH (1989-2005)
  • Ford L9522 (1998)
  • Ford L9501 (1997-1998)
  • Ford LT8513 (1996-1998)
  • Ford LT8501 (1997-1998)
  • Ford LT9501 (1997-1998)
  • Ford LT9522 (1997)
  • Ford LT9513 (1996-1997)
  • Ford L9513 (1996-1998)
  • Ford AT9522 (1997-1998)
  • Ford AT9513 (1996-1998)
  • Ford L8511 (1998)
  • Ford L8513 (1996-1998)
  • Ford L8501 (1997-1998)
  • Sterling Truck AT9500 (1999-2008)
  • Sterling Truck LT8500 (1999-2008)
  • Sterling Truck LT9500 (1999-2008)
