Monroe 34671 - Gas-Magnum Suspension Shock Absorber
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
MONROE part description
Product Description
Gas-Magnum Suspension Shock Absorber
Features & Benefits
- DESIGNED FOR TRUCKS AND VANS -- Engineered for hardworking full-size trucks and vans and features full-displaced valving on compression cycles to deliver controlled ride and handling
- BUILT TO LAST -- Heavy-duty nitrocarburized rod (non-dust shield units only) and sintered iron piston enhance durability for longer service life while self-lubricating fluid seal reduces friction against piston rod to reduce wear
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- LONGER SERVICE LIFE -- Larger bore and bigger 2-in. reserve tube work together to hold more oil for greater capacity to allow the shock to work efficiently for controlled ride and longer service life
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
Product Attributes
| 9791 | LS26 |
| 9789 | LS26 |
| Dust Shield Included | Yes |
| 9783 | No |
| 9908 | Yes |
| 9792 | No |
| Part Description | Shock Absorber |
| Compressed Length | 13.625 IN |
| Dust Shield Material | Metal |
| Extended Length | 21.625 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 8 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 38.1MM Sleeve OAL |
| Compressed Length | 346.1 MM |
| Extended Length | 549.3 MM |
| Travel Length | 203.2 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598050557 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
Part Interchanges
- Ford F75Z18124CA
- Ford F75Z18124CB
- Ford F75Z18124DA
- Ford F75Z18124DB
- Ford F75Z18124FA
- Ford F75Z18124FB
- Ford F75Z18124LA
- Ford F75Z18124LAA
- Ford F75Z18124TA
- Ford F75Z18124UA
- Ford F75Z18124UB
- Ford F75Z18125AC
- Ford F75Z18125AD
- Ford F75Z18125AE
- Ford F75Z18125AF
- Ford F75Z18125DB
- Ford F75Z18125KB
- Ford F75Z18125KC
- Ford F75Z18125LB
- Ford F75Z18125LC
- Ford F75Z18125NB
- Ford F75Z18125NC
- Ford F75Z18125UB
- Ford F75Z18125UC
- Ford F85Z18124FA
- Ford XL1Z18124AA
- Ford XL1Z18125AA
- FCS Auto Parts 342505
- KYB 344267
- Gabriel 58717
- FCS Auto Parts 342500
- Rancho RS5118
- Rancho RS55118
- NAPA Shocks 76671
- FCS 342500
- FCS 342505
- KYB KG54320
- KYB 344377
- KYB 565005
- KYB 565007
- KYB KG54319
- Sensen 12140148
MONROE 34671 Cross Reference
We have 6 alternatives for the 34671 by MONROE:
Fits Vehicles
- Ford Expedition (1997-2002)
