Name: MGM Brakes MJS3028ET951 Air Brake Chamber - Combination, 2.25" Welded Yoke
SKU: mjs3028et951
Price: 490.49 USD
Availability: InStock

MGM BRAKES part description

Specifications

Aftermarket Unit
Port Size: 3/8-18 NPTF
Welded Yoke
Stroke (in.): 3.00

Service Size: 30
Spring Size: 28

Features & Benefits

Tamper Resistant Design
Lighter Weight
3 inch (76.2 mm) Long Stroke
Compact Size
Patented Integral Release Bolt Mechanism -Minimal Bolt Protrusion -Approx. 1.25 inch (31.8 mm) Protrusion On "Long Stroke" Models When Manually Released
Lower Hold Off Pressure (Less Air Consumption)
Epoxy Coated Return Spring
Non-Coil Clash Power Spring
Increased Corrosion Resistance -Steel head, Epoxy Coated
Available With 1,749 lb (793.3 kg) -2,450 lb (1,111.3 kg) of Push-Rod Braking Force @ 1.25 inch (31.8 mm) Stroke/Service Brake Sizes 17-36
Center Hole Shield

Model: MJS3028ET

Technical Data

Stroke	3.00" (76.2 mm)
Weight lb (kg) Combination	23.10 lb (10.5 kg)
Weight lb (kg) Single	14.92 lb (6.8 kg)
A	10.73" (272.5 mm)
B	8.43" (214.1 mm)
C	8.32" (211.3 mm)
D	7.50" (190.5 mm)
E	4.75" (120.7 mm)
F	5/8" - 11 UNC
Inlets	3/8" - 18 NPTF
Y	2.25"

Replacement Parts

1	Kit -NP Chamber (a)	9015902
2	Kit -Nuts & Bolts	9003001
3	Clamp Band Assembly	8216045
4	Diaphragm	8017838
5	Kit -Push-Rod Assembly (a) SAE w/ Welded Yoke	9075001
6	Return Spring	8068022
7	Kit -Center Hole Shield	9065002
8	NP Chamber Assembly (a)	9015216
9	Kit -Nuts & Washers SAE	9002001
10	Hex Nut -Yoke SAE	N/A
11	Kit -Breather Tube	9081001
12	Kit -Piggyback Plus SAE	MJS3028ET008
*NOTE:	(a)To ensure correct stroke alert positioning, kits MUST only be used on the designated MGM brake units.
