Horton 999504 - Engine Cooling Fan Clutch
$1,34049
MSRP: $1,823.76
Save: $483.27
Limited Availability
HORTON part description
Service # | OEM # | A | A1 | B | BC | C | D | E | F | G | H | J | TMfg |
999504 | 989504 | 5.78 | - | 6.85 | 8PK | 2.25 | 3.50 | 2.56 | 1.07 (.375-24) | 2.01 | 4.41 | - | KENWORTH PETERBILT |
Col. Label | Value Name |
---|---|
A | Back Pulley Diameter |
A1 | Front Pulley Diameter |
B | Overall Length |
BC | Belt Configuration |
C | Belt Groove Location |
D | Bolt Circle |
E | Fan Pilot Diameter |
F | Fan Blade Stud Length |
G | Vertical Mounting Distance |
H | Horizontal Mounting Distance |
J | Center of JB to Top Right Mounting Hole |
TMfg | Truck Manufacturer |
Product Description
Engine Cooling Fan Clutch
Additional Information
Country of Origin (Primary) | US |
Harmonized Tariff Code (Schedule B) | 8483604040 |
Harmonized Tariff Code (HTS) | 8483604040 |
NAFTA Preference Criterion Code | B |
Warranty Distance | 300000 |
Warranty Distance UOM | DH |
Warranty Special | 7500 Hours |
Warranty Special UOM | TX |
Warranty Time | 36 |
Warranty Time UOM | MO |
VMRS Code | 042003131 |
Part Interchanges
Horton® is a world-renowned manufacturer of high-grade engine cooling solutions for the trucking industry for over 65 years. This company believes that improved airflow translates to better performance, reduced emissions, more significant fuel savings, and happy customers. Horton offers best-in-class fans, fan drives, and clutches for on-highway big rigs like heavy-, medium-, and light-duty trucks, R.V.s, buses, refuse vehicles, commercial vehicles, and other applications. This company also takes pride in its off-highway and heavy-duty products, including sweepers, agricultural tractors, mining trucks, aerial work platforms, excavators, generators, articulated vehicles, and industrial compressors. Made to operate in harsh environments, these Horton products withstand temperature extremes, dust, dirt, chemicals, as well as stop-and-go driving. For truck parts that consume less fuel, last longer, and run quieter, trust no other brand than Horton.
