HORTON part description

Product Description

Engine Cooling Fan Clutch

Application Summary

FREIGHTLINER, KENWORTH, STERLING, VOLVO

Features & Benefits

  • State-of-the-art dust seal extends fan drive life
  • Premium Friction Liner for longer lasting performance
  • Patented System Sentry Fuse for advanced fan drive protection
  • Superior Hub Bearing provides extended line and moisture resistance
  • Rebuilds fan Drive to be the same as new

Uses sintered friction facing material.

Product Attributes

BACK PULLEY DIAMETER 6.2
BELT CONFIGURATION 3V
Belt Groove Location 2.37
BOLT CIRCLE 3.5
FAN PILOT DIAMETER 1.99
HORIZONTAL MOUNTING DISTANCE 5.32
Overall Length 6.68
VERTICAL MOUNTING DISTANCE 8.58

Additional Information

Country of Origin (Primary) US
Harmonized Tariff Code (Schedule B) 8483604040
Harmonized Tariff Code (HTS) 8483604040
NAFTA Preference Criterion Code B
OEM's Part Number 981342
Warranty Distance 200000
Warranty Distance UOM DH
Warranty Special 2500 Hours
Warranty Special UOM TX
Warranty Time 24
Warranty Time UOM MO
VMRS Code 042003131

Part Interchanges

HORTON 991349 Cross Reference

We have 1 alternatives for the 991349 by HORTON:
