GATES part description

Product Description

PowerGrip Premium Timing Component Kit with Water Pump (TCKWP)

Application Summary

1999-1996 Subaru, Legacy, 4-Cyl. 2.5 L, Timing Component Kit

Features & Benefits

  • Total solution for any application: Includes belts, idler(s), tensioners, tensioner springs, water pump, supporting hardware, detailed installation instructions and Technical Service Bulletins for troublesome applications
  • Water pumps are designed and built for long lasting, efficient cooling
  • Hydraulic tensioners included, where needed
  • Everything you need to do the job right, all in one box
  • Gates warranty matches the original manufacturer's timing belt replacement intervals - not just for parts - but also for labor and other associated costs
  • Gates warranty matches the original manufacturer's timing belt replacement intervals – not just for parts – but also for labor and other associated costs

Product Attributes

Grade Type OE Performance
Number of Components 7
Installation Tool Included Yes
Belt Quantity 1
925 1.181 IN
Cog Quantity 281
Timing Marks Yes
Belt Material HSN, Fiberglass Cord
Tooth Type Modified Curvilinear (III)
9826 2
Tensioner Type Hydraulic
9825 3
Bolt Included Yes
Spring Quantity 0
Bolt Quantity 1
9827 1
Gasket Or Seals Included Yes
Gasket Quantity 1
9841 1
Contents Belt, Tensioner, Hydraulic Tensioner, 3 Idlers, Water Pump, Bolt, Bushing, Tool, Gasket, O-Ring
Instruction Sheet Number 0098-1638
Installation Instructions Included Yes
Belt Top Color Black
Timing Belt Included Yes
Springs Included No
Tensioner Included Yes
10004 Yes
Timing Belt Width 1 (in) 1.181
Timing Belt Width 1 (mm) 30
Timing Belt 1 Teeth Quantity 281

Additional Information

Harmonized Tariff Code (Schedule B) 8413309090
Country of Origin (Primary) CN
UPC 00770075527138
VMRS Code 045008153
UNSPSC 26111811

Part Interchanges

Fits Vehicles

  • Subaru Impreza (1998)
  • Subaru Legacy (1996-1999)
  • Subaru Forester (1998)
