Gates 85389 - CM2TDL MegaFlex Connected Twin-Line 2-Wire Braid Hose-SAE 100R16-XtraTuff Cover
$1,30099
5 day lead time
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
CM2TDL MegaFlex Connected Twin-Line 2-Wire Braid Hose-SAE 100R16-XtraTuff Cover
Features & Benefits
- For use with GlobalSpiral Couplings [G20 Series] and MegaCrimp Couplings [G25 Series]
- No need to use clamps as the two lines are vulcanized together to form one single unit
- Provides bend radius up to 1/3 of the SAE specification and greater flexibility for easier routing
- Tested to industry-leading 600,000 impulse cycles
- XtraTuff hose lasts up to 25 times longer than standard hose
- Meets Flame Resistance Acceptance Designation MSHA 2G
- Temperature Range: -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C)
Product Attributes
| Product Type | CM2TDL MegaFlex Connected Twin-Line 2-Wire Braid Hose - SAE 100R16 - XtraTuff Cover |
| Industrial Description | 6CM2TDL-XTFX50FT |
| Type | Hydraulic Hose |
| Hose Pressure Description | High Pressure |
| Maximum Working Pressure | 4800 PS |
| Burst Pressure | 19200 PS |
| Temperature Rating | -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C) |
| Length | 50 FT |
| 9941 | 6 |
| Inside Diameter | .375 IN |
| Outside Diameter | .70 IN |
| 9879 | 3.5 IN |
| Tube Description | Black, Oil-Resistant, Synthetic Rubber |
| Hose Material | Nitrile - Type C |
| Reinforcement Material | Two Braids, High-Tensile Steel Wire |
| Cover Material | Synthetic Rubber - Modified Nitrile - Type C2 - Color Coded Layline |
| Cover Type | Type C2 - Flame, Oil, Abrasion & Weather Resistant |
| Cover Color | Black |
| 9856 | GlobalSpiral, MegaCrimp |
| 9453 | 100R16 |
| 9954 | 857 2SC |
| 9953 | 1436 |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4009410000 |
| UPC | 00770075433668 |
| VMRS Code | 059032029 |
| UNSPSC | 40142020 |
