Name: Haldex MA15779 Maxibrake® I-Series Spring Brake - 3675 (Service Chamber Size)
SKU: ma15779
Price: 559.49 USD
Availability: InStock

HALDEX part description

Product Description

Brake Chamber Maxibrake 3675Kc

Application Summary

MAXIBRAKE® 3675 Universal Spring Brake - I Series 36"

Features & Benefits

Equipped with all-steel housing for durability and maximum protection against corrosion
Steel piston and nylon bearings help diffuse lateral and twisting motion
Epoxy-coated steel alloy springs for remarkable rust and corrosion protection
Optional spring force and deeper spring cavities deliver consistent output and longer lifespan
Cannot be released manually to ensure the truck will not move until the air supply is at a safe level

Haldex MAXIBRAKE® Universal Air Brake Spring Brake

Manufactured in ISO- and QS-certified facilities and using high-quality materials and advanced production processes, the Haldex MAXIBRAKE® universal air brake spring brake ensures long-term durability and reliable performance. This pull-type spring brake meets the industry's strict quality standards and delivers outstanding value mile after mile.

Product Attributes

Freight Class	70
Maximum Pressure	125 PSI
Push Rod Length	8 in.
Series	Maxibrake® I-Series
Service Chamber Size	36/75

Additional Information

Country of Origin (Primary)	MX
Harmonized Tariff Code (Schedule B)	8412310080
Harmonized Tariff Code (HTS)	8412310080
Remanufactured Part	N
Warranty Distance	100000
Warranty Distance UOM	MI
Warranty Special	See Haldex Aftermarket Product warranty Policy (L20221W).pdf
Warranty Time	12
Warranty Time UOM	MO
UPC	00767653016962
VMRS Code	013004009

Part Interchanges

Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.

HALDEX MA15779 Cross Reference

We have 2 alternatives for the MA15779 by HALDEX:
