(888) 312-8812 Login SignupHALDEX KN55001 Air Brake Manual Slack Adjuster - 1-1/4"-24 Spline, 5.5 in. Arm Length
Tap to view 1 more
MSRP: $106.55
$8549
Save $21.06
Limited availability at this price!
In Stock
Get it by Friday, Feb 6
HALDEX KN55001 Part Description
Manufacturer
Product Description
Manual Brake Adjuster Arm Length 5.5 Offset
Application Summary
BUSHING NUMBER - 45210129. , Meritor
Features & Benefits
- Made of forged steel for superior durability
- Assemblies are plated to provide superior rust protection
- With press-out arm hole bushings and can accommodate up to 26,000 inch lbs.
- Bi-directional design
- Permanently lubricated for maximum efficiency
- Forged steel 26,000 Inch Lbs.
- Designed with a positive locking mechanism that is corrosion resistant
- Permanently lubricated, yet are equipped with zerk fittings for optional lubrication
- Offers superior rust protection since assemblies are plated
- Positive lock mechanism is protected from rust and corrosion by plating and shaft sealing
- Product comes with zerk fitting for optional lubrication
- Press-out arm hole bushings
- Built to last for years to come
- Straight Arm - Manual Brake Adjusters
Haldex Air Brake Manual Slack Adjuster
Prevent costly downtime due to a faulty manual brake adjuster—replace it at once with the Haldex air brake manual slack adjuster. This straight arm adjuster is made to meet or exceed OEM standards to ensure the highest quality at a competitive price.
HALDEX KN55001 Specifications
Product Attributes
| Arm Length | 5.5 in. |
| Body Angle | 0 DD |
| Freight Class | 70 |
| Offset | 0 in. |
| Pin Diameter | 1/2 in. |
| Spline Diameter | 1-1/4 in. |
| Spline Quantity | 24 |
| Arm Hole Diameter | 0 |
Additional Information
| Country of Origin (Primary) | IN |
| Harmonized Tariff Code (Schedule B) | 8716905060 |
| Harmonized Tariff Code (HTS) | 8716905060 |
| Remanufactured Part | N |
| Warranty Distance | 100000 |
| Warranty Distance UOM | DH |
| Warranty Special | 24 MO, 200,000 MI=All Other Tour Bus, Intercity Transit Products Not Listed(8). 12MO,100,000 MI= All Other New Products Not Listed(13), City Transit Oper.(9) (All New Products), Friction Products(7), New Clutches(6). See L20221W.pdf for warranty details |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| Core Group | - |
| UPC | 00767653012278 |
| VMRS Code | 013002028 |
HALDEX KN55001 Cross References
| Brand | Part Number |
|---|---|
| 013-002-028, R825020, MIDKN55001, HDXKN55001 | |
| BWP-NSI | M-3984, R-5201 |
| Bendix | 106384 |
| Blue Bird | 1321058, 331-1321058 |
| Crewson Brunner | CA5201 |
| EUCLID | E-9102 |
| Eaton | 506825 |
| Ford | E9HT2308CA, E9HZ-2308CA, E9HZ2308C |
| Freightliner | 681 420 04 49, 6814202349 |
| HALDEX | KN55001 |
| Hercules | H2030A |
| Hercules mfg | H2030A |
| Mack | 25QD352, 5000452440 |
| Midland | KN55001, MPN21166B, MRN21166B, N21166AB, N21166AD, N21166B, N21166C, N21166D, N21166E, VN21166B, VN21166C |
| N/A | E-9102, H2030A, KN55001, 106384, 506825, CA5201, E9HT2308CA, 6794973, 1658927C1, A19-3275-L-1052, 25QD352, 681 420 04 49, 76401-3201 |
| NAVISTAR | ZZKN55001 |
| Navistar | 1658927C1, 1693170C1, 1693170C2, 580965C91 |
| ROCKWELL | A19-3275-L-1052, A3-3275-L-1052, A4-3275-L-1052, R825020 |
| Rockwell International | A19-3275-L-1052, A3-3275-L-1052, A4-3275-L-1052, R825020 |
| Stemco | CA5201 |
| Volvo | 6794973, 76401-3201 |
| Volvo GM Heavy Truck | 76401-3201 |
| WORLD AMERICAN | WAKN55001 |
HALDEX KN55001 Customer Reviews
No reviews yet
Be the first to review this product!
HALDEX KN55001 Manufacturer Information
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
