HALDEX KN20611 Part Description
Manufacturer
Product Description
Manifold Dash Valve
Features & Benefits
- Manifold Dash Valve, Engineering Grade Composite (EGC) - One Piece Housing. Ports have molded identification. Completely serviceable. 2 Spools.
- A manifold dash valve that installs easily
- With one-piece housing that’s made of Engineering Grade Composite (EGC), which is proven tough, light, and corrosion resistant
- Product’s ports have molded identification
- Completely serviceable and features two spools
Haldex Hand Operated Valve
The Haldex hand operated valve enables the user to manually reduce incoming pressure to the desired output pressure. Manufactured by a brand with over 100 years of engineering expertise, this hand control valve delivers superior performance, reliability, and efficiency.
HALDEX KN20611 Specifications
Product Attributes
| Auxiliary Supply Port Diameter | 1/4 in. |
| Delivery Port Diameter | 1/4 in. |
| Exhaust Port Diameter | 1/4 in. |
| Freight Class | 70 |
| Mounting Position | Horizontal - 4 Holes, .25-20 Well Nuts in Body |
| Non-Override Pressure | 25 ± 5 PSI |
| Pressure Rating | 20 - 45 PSI |
| Reservoir Port Diameter | 2 @ 1/4 in. |
| Spool Quantity | 2 |
| Auxiliary Supply Port | .25 |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8481200070 |
| Harmonized Tariff Code (HTS) | 8481200070 |
| Remanufactured Part | N |
| Warranty Distance | 100000 |
| Warranty Distance UOM | DH |
| Warranty Special | 36 MO, 350,000 MI=Haldex Air Brake Valves(1), Automatic Drain Valves (410-10XXX Series)(1). 12 MO, 100,000 MI= Automatic Drain Valves (N20878/ N20879 Series), Height Control Valve, Scale-O-Matic and AC Boxes. See L20221W.pdf for warranty details |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| Core Group | - |
| UPC | 00767653010113 |
| VMRS Code | 013010050 |
HALDEX KN20611 Cross References
| Brand | Part Number |
|---|---|
| 013-010-050, RKN20611 | |
| Bendix | 065186, 065187, 101890, 104863, 107220, 107433, 5000286, 5000379, 5000884, 5001230, 5005057, 5005058, 5005059, 5005067, 5005080, 5005081, 65186, 65187, 800036, 800082, 800519, 800520, 800526, 800573 |
| Bepco | 065160 |
| Genuine Newstar | S-11528 |
| HALDEX | KN20611 |
| Haldex | N4400B, N4400EH, RKN20611 |
| MERITOR | R955800573N, R955800519N |
| Mack | 5396-KN20611, 745065186, 745101890 |
| Meritor | 9366490050, RKN20611 |
| Midland | 065187X, KN20611, N4400B, N4400EH, N4400L |
| N/A | KN20611, 065187X, 065186, 9366490050, EM-34570, 065160, 2039879C91, 5396-KN20611, 3949780 |
| Navistar | 2039879C91, 2039879C92, BX065187, ZZKN20611 |
| PAI | EM-34570, EM-56480, LVM-3457 |
| Volvo | 3949780, 79101-3201 |
| Volvo GM Heavy Truck | 3949780, 79101-3201 |
| WABCO | RKN20611 |
| WORLD AMERICAN | WAKN20611 |
