Name: Murphy L150 Liquid Level Swichgage with Low-Limit Switch, 25 PSI Max OP, Brass Float
SKU: l150
Price: 254.99 USD
Availability: InStock

MURPHY part description

Features & Benefits

Maximum Temperature: 250° F (121° C)
Maximum Operating Pressure: 25 PSI (172 kPa)
Case: Die cast aluminum, polyurethane coated; approximate dimensions; 4-1/2 x 4-3/4 x 2-3/4 in. (114 x 121 x 70 mm)
Mounting Holes: (2) 9/32 in. (7 mm) diameter at 4-1/2 in. (114 mm) on center
Float: Brass
Lens: Polycarbonate
O-rings: Saturated Nitrile, suitable for coolant or hydrocarbons
Gasket: Nitrile
Vent Tube: 1/4 x 5 in. (6 x 127 mm) copper cane with 1/4 NPT x 1/4 in. (6 mm) tube fitting
Contact Rating: 2 A @ 30 VAC/DC. Wire: (1) 16 AWG x 26 in. (1.5 mm 2 x 660 mm) with terminals

Combination Liquid Level Gauge and Low Limit Switch@ Contains a Chamber with Pivotal Float and an Indicating Dial with Pointer@ Float Operates the Pointer which Closes a Switching Circuit if Fluid Level Falls to the Low-Limit Set Point.

For over 75 years, FW Murphy® has been the leader in engine instrumentation and control solutions for heavy duty and industrial applications. The company is highly popular for its line of Swichgage indicator gauge, which was initially developed in the 1930s and remained one of the brand’s best selling products. Today, FW Murphy offers a comprehensive portfolio that includes temperature and pressure gauges, compressor control panels, turnkey ignition systems, mag switches, and other related components and accessories. These products are manufactured in ISO9001- facilities in Texas and Hangzhou, China following strict quality standards. A two-year limited warranty also covers all FW Murphy products.
