Haldex GC3030S1 - Air Brake Spring Brake - Standard Stroke, 6.8" Piggyback Length, 1.8" Pushrod Length
$8650
MSRP: $156.26
Save: $69.76
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
HALDEX part description
Product Description
Combination with Clevis & Boot - Size 3030 (S1 = 330° Service)
Application Summary
Combination with Clevis & Boot - Size 3030 (S1 = 330° Service)
Features & Benefits
- Uses superior power spring technology for unparalleled force output consistency
- Has powder-coated housing that effectively resists fatigue and corrosion
- World-class diaphragm that’s made of high-quality rubber compound for superior flexibility and heat- and cold-resistance
- With rugged powder-coated service housing for corrosion protection
- Self-piloting dust shield extends air brake system lifespan
- Comes in a variety of sizes to fit all drum brake applications
Haldex GoldSeal Air Brake Spring Brake
Equip your vehicle with a high-quality Haldex GoldSeal air brake spring brake. This product is the only truly sealed double diaphragm spring brake specifically designed for heavy duty applications.
Product Attributes
| Air Port Position | 90° |
| Air Port Thread Diameter | 3/8-18 NPTF |
| Bracket to End of Spring Housing Length | 9 in. |
| Clevis Pin Length | 3 in. |
| Finish | Powder Coated |
| Freight Class | 70 |
| Grade | 5 |
| Housing Material | 9 Gauge Steel |
| Maximum Pressure | 150 PSI |
| Piggyback Length | 6.8 in. |
| Push Rod Diameter | 5/8-18 UNF |
| Push Rod Length | 1.8 in. |
| Series | GoldSeal |
| Service Chamber Size | 30/30 |
| Service Clampband Position | 0° |
| Service Clampband Size | 10.2 in. |
| Spring Housing Flange Size | 8.3 in. |
| Stroke Length | 2.5 in. |
| Stroke Type | Standard |
| Stud Distance | 4.75 in. |
| Stud Length | 1.5 in. |
| Stud Type | 5/8-11 UNC |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8412310080 |
| Harmonized Tariff Code (HTS) | 8412310080 |
| Remanufactured Part | N |
| Warranty Distance | 100000 |
| Warranty Distance UOM | MI |
| Warranty Special | See Haldex Aftermarket Product warranty Policy (L20221W).pdf |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| UPC | 00767653303239 |
| VMRS Code | 013004027 |
Part Interchanges
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
