(888) 312-8812 Login SignupHALDEX GC2024 GoldSeal Double Diaphgram Spring Brake - 2024 (Service Chamber Size), 2.25 in. Stroke Length, Standard Stroke
Tap to view 1 more
$17549
Limited availability at this price!
In Stock
Get it by Monday, Feb 16
HALDEX GC2024 Part Description
Manufacturer
Product Description
Brake Chamber GoldSeal 2024
Application Summary
Combination - Size 2024
Features & Benefits
- Uses superior power spring technology for unparalleled force output consistency
- Aluminum center body is durable, lightweight and corrosion resistant
- Has powder-coated housing that effectively resists fatigue and corrosion
- Double oring center seal and wears rings extend service life and protect against air leakage between chambers
- Comes with two O-rings for positive sealing and plastic bearings for extended life
- Epoxy coated clamp band and service return spring for additional corrosion resistance
- World-class diaphragm that’s made of high-quality rubber compound for superior flexibility and heat- and cold-resistance
- Heat treated power springs for maximum output force and extended life, powder coated for corrosion protection
- With rugged powder-coated service housing for corrosion protection
- Patented orange alert stoke indicator is visible when brakes are out of alignment
- Orange Alert® Stroke Indicator effectively informs the user if brake maintenance is required
- Self-piloting dust shield extends air brake system lifespan
- Comes in a variety of sizes to fit all drum brake applications
Haldex GoldSeal Air Brake Spring Brake
Equip your vehicle with a high-quality Haldex GoldSeal air brake spring brake. This product is the only truly sealed double diaphragm spring brake specifically designed for heavy duty applications.
HALDEX GC2024 Specifications
Product Attributes
| Air Port Position | 90 |
| Air Port Thread Diameter | 3/8-18 NPTF |
| Bracket to End of Spring Housing Length | 8.6 in. |
| Finish | Powder Coated |
| Freight Class | 70 |
| Grade | 5 |
| Housing Material | 9 Gauge Steel |
| Maximum Pressure | 150 PSI |
| Piggyback Length | 6.3 in. |
| Push Rod Diameter | 5/8-18 UNF |
| Push Rod Length | 9.68 in. |
| Series | GoldSeal |
| Service Chamber Size | 20/24 |
| Service Clampband Position | 0° |
| Service Clampband Size | 8.7 in. |
| Spring Housing Flange Size | 7.5 in. |
| Stroke Length | 2.25 in. |
| Stroke Type | Standard |
| Stud Distance | 4.75 in. |
| Stud Length | 1.5 in. |
| Stud Type | 5/8-11 UNC |
Additional Information
| Country of Origin (Primary) | MX |
| Harmonized Tariff Code (Schedule B) | 8412310080 |
| Harmonized Tariff Code (HTS) | 8412310080 |
| Remanufactured Part | N |
| Warranty Distance | 100000 |
| Warranty Distance UOM | DH |
| Warranty Special | See Haldex Aftermarket Product warranty Policy (L20221W).pdf |
| Warranty Time | 12 |
| Warranty Time UOM | MO |
| Core Group | - |
| UPC | 00767653297910 |
| VMRS Code | 013004027 |
HALDEX GC2024 Cross References
HALDEX GC2024 Customer Reviews
No reviews yet
Be the first to review this product!
HALDEX GC2024 Manufacturer Information
Haldex® is a Sweden-based manufacturer specializing in brake and air suspension systems for heavy duty vehicles. Its product line consists of brake components for wheel ends, including disc brakes, brake adjusters, and actuators. It also offers air control products such as compressed air dryers, valves, ABS, and EBS. All these Haldex products are designed with safety and efficient operation in mind, cutting down on potential hazards and maintenance costs in the long run. Today, Haldex runs manufacturing and R&D facilities in 19 countries across four continents. It is dedicated to producing high-quality brake and suspension parts for its customers all around the world as well as developing new technologies for the future.
