ConMet 104166 - FRONT ALUM HUB - ABS
$39099
MSRP: $545.85
Save: $154.86
In stock
limited availability at this price!
. Learn more
CONMET part description
| Hub Assembly Data | |
| Hub Assembly | 104166 |
| Aftermarket Assembly | 10083788 Compare |
| Status | Terminated (This assembly has been superseded by 10018124) |
| Assembly Type | Basic Hub Assembly |
| Axle Location | Front |
| Axle Name | FF |
| Axle-Specific Specification | 5.06" |
| Mounting | Hub Piloted - 10 Studs |
| ABS | Yes |
| ABS Characteristic | Has Stamped ABS Ring |
| Wheel Stud Bolt Circle Diameter | 285.75 mm |
| Wheel Stud | 102033 |
| Wheel Stud Standout | 2.47" |
| Hub Rating | 7,300 LBS 3,311 kg |
| Hub Cap Bolt Circle Diameter | 4.500" |
| Drum Pilot Diameter | 8.78" |
| Bearing Set | Standard |
| Fill Hole | No Fill Hole |
| ABS Offset | 1.53" |
| Hub Offset | 5.06" |
| Weight | 34.5 LBS 15.6 kg |
| Machining | 104115 |
| Machined Flange Thickness | 1.50" |
| Casting | 101945 |
| Casting Material | A356.0-T61 Aluminum |
| Superseded By | 10018124 |
| Bill of Materials Ñ 104166 Ñ Basic Hub Assembly | |||||
| Item | Description | Material | Qty | Unit | Type |
|---|---|---|---|---|---|
| 103706 | RING, ABS | MILD STEEL | 1 | EA | ABS Tone Ring |
| 102033 | STUD, WHEEL - PROP CL 10.9 | M22 X 1.5MM X 3.97 LG | 10 | EA | Wheel Stud |
| 100209 | CUP, BEARING - OUTBOARD | 3720 | 1 | EA | Bearing Cup |
| 100015 | CUP, BEARING - INBOARD | HM212011 | 1 | EA | Bearing Cup |
| 104115 | HUB, MACHINED | 101945 HUB, CAST ALUM | 1 | EA | Hub Machining |
| 101945 | HUB, CASTING | A356-T6 ALUMINUM | 1 | EA | Hub Casting |
ConMet® is the market leader in wheel hubs, aluminum castings, and plastic components for commercial vehicles. It traces back its roots to 1964 when it started as a part of Portland Freightliner, a subsidiary of Consolidated Freightways. More than 30 years later, it began its operation under Amsted Industries, a global manufacturer of components serving the vehicular, railroad, construction, and industrial markets. Headquartered in Vancouver, Washington, ConMet takes pride in its patented innovations, including PreSet®, PreSet Plus®, and TruTurn® product lines. It uses cutting-edge design technologies, such as Solidification Modeling and Finite Element Analysis, and it works hand-in-hand with OE manufacturers to provide highly engineered solutions that best meet the customers' needs.
