GUNITE part description

15.00x4.00 Brake Drum TRU-PILOT

Specifications

Drum Specifications:
Finished Weight: 79
Maximum Wear Diameter: 15.12
Drum Mount: Outboard
Drum Type: BEA
Wheel Type: Disc
A - Overall Diameter: 17.32
B - Dust Shield Recess Diameter: 16
C - Dust Shield Recess Depth: 0.8
Brake Size: 15.00x4.00
D - Brake Surface Diameter: 15
E - Brake Surface Witdh: 4.66
F - Mounting Flange Diameter: 13.38
G - Overall Depth: 9.18
H - Pilot Diameter: 8.78
I - Bolt Circle Diameter: 11.25
J - Number of Bolt Holes: 10
Bolt Hole Size: 1.25
K - Squealer Band Width: 1.58
L - Mounting Flange Thickness: 0.5
M - Outside Sidewall Diameter: 16.01
N - Sidewall Offset: 4.3
O - Inside Finished Diameter: 13.2
Special Information: Double pilot version of 3726X.
Brake Type Hydraulic
Brake Size 15 x 4
Bolt Holes And Size 10 - 1.31
Bolt Circle Diameter (In.) 11.25
Pilot Diameter (In.) 8.78
Overall Depth (In.) 9.04

GUNITE 3800X Cross Reference

We have 5 alternatives for the 3800X by GUNITE:

Heavy-duty truck and trailer manufacturers rely on Gunite® for high-quality brake drums, brake rotors, slack adjusters, hubs, and hub assemblies. A brand under Accuride Corporation, an industry leader in the manufacturing of wheels and wheel-end components for the global commercial vehicle markets, Gunite delivers world-class quality by designing and manufacturing its products in its own factory located in Rockford, Illinois. Gunite’s aluminum brake drums and other products go through rigorous vehicle field testing at fleets to ensure reliable performance even under extreme road conditions. They are proven, year after year, as the industry standard in providing maximum performance, long-term reliability, and reduced maintenance costs.
