Name: WABCO 4721950980 ABS Modulator Valve
SKU: 4721950980
Price: 315.49 USD
Availability: InStock

WABCO part description

ABS Solenoid Modulator Valve

Product Attributes

Weight	1.5013
Calculated Volume (dm³)	0.75
Port thread 1	1/2" - 14 DRYSEAL NPTF
Size	118 x 106 x 60
Voltage	12 V
Temperature Range	-40°C to +80°C
Max. operating pressure	11.0 bar
Distance Between Holes	71x20 mm
Exhaust	Integrated silencer
Protection class	IP 68 / IP 69K
Electrical connection	Bayonet DIN 72 585 A1-3.1-Sn/K1
Port thread 2	1/2" - 14 DRYSEAL NPTF
Rated current	2220 mA

WABCO 4721950980 Cross Reference

We have 11 alternatives for the 4721950980 by WABCO:

Whether it’s for cars, buses, trucks, or trailers, WABCO® is at the frontline at developing and providing products and systems to make vehicles safer and easier to control. Founded in 1869, WABCO is a major supplier of braking, stability, suspension and transmissions in the Americas and beyond. The company is recognized as introducing the modern air brake system in 1869, and continues to lead the industry in air brake design and production for the heavy duty and commercial vehicle sectors. Today, WABCO operates as a division of the German auto parts maker ZF and employs 16,000 employees in facilities in 36 countries worldwide.
