(888) 312-8812 Login SignupGATES TR22416 Green Stripe Truck & Bus Series V-Belt
Tap to view 1 more
MSRP: $59.22
$2599
Save $33.23
Limited availability at this price!
In Stock
Get it by Thursday, Jan 8
GATES TR22416 Part Description
Manufacturer
Product Description
Green Stripe Truck & Bus Series V-Belt
Application Summary
1978-1975 Toyota, Land Cruiser, 6-Cyl. 258, Fan & Alt.
Features & Benefits
- Molded notches reduce bending stress, especially on small diameter pulleys, while dissipating heat
- High modulus, high strength tensile cord
- Oil and heat-resistant construction throughout
- Meets SAE J636b and SAE J637 specifications
- Meets RMA oil and heat resistant standards and static conductivity requirements
- NOTE: Some sizes available as Gates PowerBand joined V-belts
GATES TR22416 Specifications
Product Attributes
| Type | Truck & Bus V-Belt |
| Cross Section Designation | RA |
| Angle | 40 |
| Strand Quantity | 1 |
| Top Width | .594 in |
| Outside Circumference | 42.24 in |
| Effective Length | 41.66 in |
| Construction | Notched |
| Notched | Yes |
| Belt Material | EPDM |
| Cord Material | Polyester |
| Top Width | 15 mm |
| Outside Circumference | 1073 mm |
| Effective Length | 1058 mm |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 4010323000 |
| UPC | 00072053274714 |
| VMRS Code | 065005003 |
| UNSPSC | 26111801 |
GATES TR22416 Part Interchanges
| Brand | Part Number |
|---|---|
| Beck/Arnley | 141-1238, 145-061000 |
| Bosch | 910416-6195 |
| Mopar | BH-85 |
| Motorcraft | JE-423 |
| Sierra | 18-22415, 18-22420 |
| White | 027000332, 027023448, 027101830, 027120853, 027136456, 049004345, 1703807, 1720593, 18296A, 542872, CO9036 |
| ACDelco | T22416 |
| Dayco | 15V1055, 22415, 22415DR, 4, 420197, 430045, 50621, 50622, 51025, 51087, 51771, 53665, 54393, 54578, 55637, 56571, 702M, 22420 |
| Leece-Neville | 52920 |
| Carquest | TR22416 |
| Allis Chalmers | 203073, 222246, 4346414, 4350215, 800116, DE46414, DE50215, U3073 |
| American Motors Corp (AMC) | 913290 |
| Arctic Traveler | 4750239 |
| Bando | 5410, B5406, B5410 |
| Bendix-Westinghouse | 213188 |
| British Leyland | 1B9391 |
| Caterpillar | 0861361 |
| Chris Craft | 2470 |
| Chrysler | 1567634 |
| Climax Engr | 41173, 41203 |
| Continental Belt | 22420MK, V302 |
| Cummins | 132261, 178574, 3040353, S2695, 177006, 178528 |
| Daihatsu | 9932301060 |
| Datsun/Nissan | 4875248270, 48752L0410 |
| Deutz-allis | 70203073, 70800116 |
| Diamond Reo | 7862J |
| Epton | 22418 |
| First Products | 22-415 |
| Fleetrite | ZAH22415 |
| General Motors | 2304072, 5120653, 5169910, 5184584, 5186386 |
| Ford | D0HA 8620 A, D0HZ 8620 E, D4197 |
| Toyota | 9091602044, 9091602073, 9094602073, 9901121599, 9934301065, 99343011060 |
| Isuzu | 1136711270, 1136712560 |
| Mitsubishi | ME035061, ME035062, ME0720183, ME900741 |
| Mazda | 175715906, 93042050 |
| International Harvester (IHC) | 22551V, 683973C1, 754885C1, 81177HA, AE1608 |
| Hyster | 63586 |
| Reo Trucks | 1296M5 |
| Hall Scott | 324357 |
| Hough | 169656H1 |
| Komatsu | 0412021742 |
| Kysor | 300321 |
| Lazorlite | L39-1000, L39-1015 |
| Mitsuboshi | MF8405, RECMF8405, REMF8405, REMF8410 |
| Poclain | C0038734 |
| Vera | 55-10758 |
| Waukesha | 41124 |
| Goodyear | 1713, 22420, 22424 |
| Volvo GM Heavy Truck | V1090867, V1091024 |
| NAPA Belts/Hose | 25-22416 |
| Alliance Truck Parts | GT22421, GT22421E |
| Durkee-Atwood | 22-423 |
| Gray Marine | D6197 |
| Grumman Flxible | 97413001 |
| John E. Mitchell | 13570 |
| MBL Three Stars | 22415 |
| NAPA | 25-10580 |
| PIX | A-70800116 |
| Service King | 119, 6342 |
| Stewart & Stevenson | 00013600012 |
| Perkins | 2612629 |
| <Unknown> | 00013600012A, 0868040001, 1340604, 1340606, 17X975, 300E3269, 542245, 592219, 638587, 638588, 7180605, 81177H, 8970435510, 8970629131, 94240372, 97043551, 97062913, A13595, A23418, B1766842, CO138761, D0HA 8620 E, D56129, DE502151, H324357 |
| Metric | 15A1055, 17A1040, 15A1065 |
GATES TR22416 Fits Vehicles
- International CO220 (1971)
- International CO200 (1970-1971)
- International CO190 (1970-1971)
- Mitsubishi Fuso FM-SP (1996, 1998-2004)
- Mitsubishi Fuso FM-MR (1996, 1998-2004)
- Mitsubishi Fuso FM-HR (1996, 1998-2003)
- Mitsubishi Fuso FM-SR (1996, 1999-2004)
- Mitsubishi Fuso FM (1986-1995)
- Mitsubishi Fuso FK (1986-2004)
- GMC W6500 Forward (1988-1989, 1992-1994)
- GMC W5500 Forward (1988-1994)
- GMC W7500 Forward (1989-1994)
- Chevrolet W7500 Tiltmaster (1989-1994)
- Chevrolet W6500 Tiltmaster (1988-1989, 1992-1994)
- Chevrolet W5500 Tiltmaster (1988-1994)
- Ford LNT9000 (1984-1989)
- Ford LT9000 (1984-1989)
- Ford LTS9000 (1984-1989)
- Ford LTL9000 (1984-1989)
- Ford LL9000 (1987-1989)
- Ford LN9000 (1984-1989)
- Ford L9000 (1984-1989)
- Isuzu NRR (1989)
- Mazda RX-4 (1974-1975)
- Toyota Land Cruiser (1969-1978)
GATES TR22416 Cross References
