(888) 312-8812 Login SignupGATES G31970-0604 6-Port Manifold (Composite SureLok)
Tap to view 1 more
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
GATES G31970-0604 Part Description
Manufacturer
Product Description
6-Port Manifold (Composite SureLok)
Features & Benefits
- Internal and external machined threads for connection to ports. Machining retains collet, tube support and O-Ring
- Tube support prevents tube collapse during severe loading conditions
- Collet teeth grip the tube, holding it firmly in the fitting
- Internal O-Ring provides a seal and necessary interference between tube and fitting body
GATES G31970-0604 Specifications
Product Attributes
| Coupling Description | Composite SureLok 6-Port Manifold |
| Industrial Description | 6AB-4MANIFOLD |
| Outside Diameter | .25 IN |
| Distance Between Mounting Holes | 2.76 IN |
| Length | 4.1 IN |
| Maximum Working Pressure | 150 PS |
| Temperature Rating | -40 Deg. F to +200 Deg. F (-40 Deg. C to +93 Deg. C) |
| Material | High Impact Nylon & Brass |
| Seal Material | O-Ring - Buna N, Thread Sealant - Precote 5 |
| Distance Between Mounting Holes | 70.1 MM |
| Length | 104.1 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 7412200085 |
| Country of Origin (Primary) | US |
| Stock Status | N |
| UPC | 00029769205785 |
| VMRS Code | 059032033 |
| UNSPSC | 27121700 |
