(888) 312-8812 Login SignupGATES G25832-1010 Female British Standard Parallel Pipe O-Ring Swivel - 90 Bent Tube (MegaCrimp)
Tap to view 3 more
$6049
Limited availability at this price!
In Stock
Get it by Monday, Jan 5
GATES G25832-1010 Part Description
Manufacturer
Product Description
Female British Standard Parallel Pipe O-Ring Swivel - 90 Bent Tube (MegaCrimp)
Features & Benefits
- Robust "bite-the-wire" crimp
- Robust “bite-the-wire” crimp
- Tested to an industry-leading 1,000,000 impulse cycles
- Simplifies inventory management
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance than the SAE Standard
- Popular thread styles also available with TuffCoat Xtreme plating for 583 percent better corrosion resistance than the SAE Standard
GATES G25832-1010 Specifications
Product Attributes
| Coupling Description | MegaCrimp Female British Standard Parallel Pipe O-Ring Swivel - 90 Bent Tube |
| Industrial Description | 10G-10FBSPORX90 |
| Thread Size | 5/8-14 |
| Inside Diameter | .625 IN |
| Hydraulic Hose Recommendation | Can Accommodate Various Hose Outside Diameters on Both One-Wire & Two-Wire Braid Hydraulic Hose |
| Nut Hex Size | 30 MM |
| Drop Length | 1.81 IN |
| Cut-Off Length | 1.83 IN |
| Length | 3 IN |
| Seal Type | Mated Angle w/O-Ring |
| Termination | British |
| O-Ring Location | On Female w/Inverted Nose Seat |
| Seat Angle | 30 |
| Gender | Female |
| Bent Tube Angle | 90 |
| Swivel | Yes |
| Inside Diameter | 15.9 MM |
| Drop Length | 46 MM |
| Cut-Off Length | 46.6 MM |
| Length | 76.3 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8412909015 |
| Country of Origin (Primary) | US |
| UPC | 00072053401363 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
GATES G25832-1010 Part Interchanges
| Brand | Part Number |
|---|---|
| Aeroquip | 1A10BFB10 |
| Parker | 1B243-10-10 |
| Dayco | 116266 |
| Weatherhead | 10U80P, 10Z80P |
| Goodyear | 14120-1010, B2-BPFX90-1010 |
| NAPA | G25832-1010 |
| Kurt Hydraulics | F-BSPX90-10-10 |
