GATES part description

Product Description

Code 61 O-Ring Flange - 90 Bent Tube (MegaCrimp)

Features & Benefits

  • Robust "bite-the-wire" crimp
  • Robust “bite-the-wire” crimp
  • Tested to an industry-leading 1 million impulse cycles
  • Simplifies inventory management
  • Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance SAE Standard
  • Popular thread styles also available with TuffCoat Xtreme plating for 583 percent better corrosion resistance than the SAE standard

Product Attributes

Termination Code 61
9934 90
Coupling Description MegaCrimp Code 61 O-Ring Flange - 90 Bent Tube
Industrial Description 8G-12FL90M
Inside Diameter .5 IN
9952 Can Accommodate Various Hose Outside Diameters on Both One-Wire & Two-Wire Braid Hydraulic Hose
Flange Thickness .27 in
Flange Diameter 1.5 IN
Drop Length 2.28 IN
9929 2.13 IN
Length 3.6 IN
Seal Type O-Ring
9927 Flange Groove
Inside Diameter 12.7 MM
Flange Thickness 6.9 MM
Flange Diameter 38.1 MM
1874 58 MM
9929 54 MM
Length 91.5 MM

Additional Information

Harmonized Tariff Code (Schedule B) 7326908688
Country of Origin (Primary) US
UPC 00072053435825
VMRS Code 059032012
UNSPSC 31163000
