Gates G20350-2020 - Code 62 O-Ring Flange Heavy (GlobalSpiral)
$8099
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
GATES part description
Product Description
Code 62 O-Ring Flange Heavy (GlobalSpiral)
Features & Benefits
- "Bite-the-wire" crimp for improved coupling retention
- “Bite-the-wire” crimp for improved coupling retention
- Tested to an industry-leading 1,000,000 impulse cycles
- +250degF temperature capability for longer assembly life
- +250°F temperature capability for longer assembly life
- Environmentally-friendly TuffCoat plating for 347 percent better corrosion resistance than the SAE Standard
Product Attributes
| Coupling Description | GlobalSpiral Code 62 O-Ring Flange Heavy |
| Industrial Description | 20GS-20FLH |
| Inside Diameter | 1.25 IN |
| 9952 | All Gates MegaSys Four and Six-Spiral Wire Hydraulic Hose Up to 8,000 psi |
| Maximum Working Pressure | 6000 PS |
| Flange Thickness | .41 in |
| Flange Diameter | 2.13 IN |
| 9929 | 2.95 IN |
| Length | 5.75 IN |
| Inside Diameter | 31.8 MM |
| Flange Thickness | 10.4 MM |
| Flange Diameter | 54.1 MM |
| 9929 | 74.9 MM |
| Length | 146.1 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 7326908688 |
| UPC | 00072053437782 |
| VMRS Code | 059032012 |
| UNSPSC | 31163000 |
Part Interchanges
- Aeroquip 1E20FH20
- Aeroquip 1Z20FH20
- Parker 16A71-20-20
- Parker 16A73-20-20
- Parker 16A78-20-20
- Parker 16A79-20-20
- Dayco 100389
- Dayco 100389U
- Dayco 102198
- Dayco 103020
- Dayco 1B20FH20
- Weatherhead 43020ED20
- Weatherhead 43020UD20
- Weatherhead 47020ED20
- Weatherhead 47020EED20
- Weatherhead 4SP20WD20
- Weatherhead 57020SD20
- Weatherhead 6SP20WD20
- Goodyear 28300-2020
- Goodyear DG-FH-2020
- Goodyear S4-FH-2020
- Goodyear S4-FH90-2020
- Goodyear S6-FH-2020
- NAPA G20350-2020
- Kurt Hydraulics C62-20-20-JJ
- Kurt Hydraulics C62-20-20-W
