(888) 312-8812 Login SignupGATES 85736 Global G2L PolarFlex Hose - SAE 100R2 Type S
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
GATES 85736 Part Description
Manufacturer
Product Description
Global G2L PolarFlex Hose - SAE 100R2 Type S
Features & Benefits
- For use with Field Attachable Type T Couplings [G28 Series], GlobalSpiral Couplings [G20 Series], GlobalSpiral Plus Couplings [G22 Series] and MegaCrimp Couplings [G25 Series]
- Tested to industry-standard 600,000 impulse cycles
- Unique low temperature tube for extended service life at extremely low temperatures
- Meets Flame Resistance Acceptance Designation MSHA 2G
- Temperature Range: -70 Deg. F to +212 Deg. F (-57 Deg. C to +100 Deg. C)
GATES 85736 Specifications
Product Attributes
| Product Type | Global G2L PolarFlex Hose - SAE 100R2 Type S |
| Industrial Description | 12G2LX50FT |
| Type | Hydraulic Hose |
| Hose Pressure Description | High Pressure |
| Maximum Working Pressure | 3100 PS |
| Burst Pressure | 12400 PS |
| Temperature Rating | -70 Deg. F to +212 Deg. F (-57 Deg. C to +100 Deg. C) |
| Length | 50 FT |
| Dash Size | 12 |
| Inside Diameter | .75 IN |
| Outside Diameter | 1.15 IN |
| Bend Radius | 9.5 IN |
| Tube Description | Black, Oil-Resistant, Synthetic Rubber |
| Hose Material | Nitrile - Type C |
| Reinforcement Material | Two Braids, High-Tensile Steel Wire |
| Cover Material | Thin Synthetic Rubber - Chloroprene - Type A |
| Cover Type | Type A - Flame, Oil & Abrasion Resistant |
| Cover Color | Black |
| Coupling Recommendation | GlobalSprial, MegaCrimp |
| SAE Standard | 100R2 |
| EN Standard | 853 2SN |
| ISO Standard | 1436 2SN R2 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4009210000 |
| Country of Origin (Primary) | MX |
| UPC | 00072053515978 |
| VMRS Code | 059032029 |
| UNSPSC | 40142020 |
GATES 85736 Part Interchanges
| Brand | Part Number |
|---|---|
| Weatherhead | H32512250R |
| NAPA | 85736 |
