Name: Gates 85492 EFG4K Spiral Wire Hose - SAE 100R12
SKU: 85492
Price: 1005.49 USD
Availability: InStock

GATES 85492 Part Description

EFG4K Spiral Wire Hose - SAE 100R12

For use with GlobalSpiral Couplings [G20 Series], GlobalSpiral One-Piece Couplings [G21 Series, -20 Only] and Stainless Steel Spiral Couplings [G18 Series]
Tested to industry-leading 1,000,000 impulse cycles
XtraTuff hose lasts up to 25 times longer than standard hose
MegaTuff hose lasts up to 300 times longer than standard hose during hose-to-hose and hose-to-metal abrasion tests per ISO 6945 and offers superior ozone and weathering resistance
Meets Flame Resistance Acceptance Designation MSHA 2G
Temperature Range: -40 Deg. F to +250 Deg. F (-40 Deg. C to +121 Deg. C)

GATES 85492 Specifications

Product Type	EFG4K Spiral Wire Hose - SAE 100R12
Industrial Description	8EFG4KX50FT
Type	Hydraulic Hose
Hose Pressure Description	Very High Pressure
Maximum Working Pressure	4000 PS
Burst Pressure	16000 PS
Temperature Rating	-40 Deg. F to +250 Deg. F (-40 Deg. C to +121 Deg. C)
Length	50 FT
Dash Size	8
Inside Diameter	.5 IN
Outside Diameter	.94 IN
Bend Radius	3.5 IN
Tube Description	Black, Oil-Resistant, Synthetic Rubber
Hose Material	Nitrile - Type C
Reinforcement Material	Four Alternating Layers of Spiraled, High-Tensile Steel Wire
Cover Material	Synthetic Rubber - Polychloroprene - Type A - Color Coded Layline
Cover Type	Type A - Flame & Oil Resistant
Cover Color	Black
Coupling Recommendation	GlobalSpiral, Stainless Steel S
SAE Standard	100R12
EN Standard	856 R12
ISO Standard	18752 Grade D, 3862 Type R12

Harmonized Tariff Code (Schedule B)	4009410000
Country of Origin (Primary)	IN
UPC	00072053496642
VMRS Code	059032029
UNSPSC	40142020
