(888) 312-8812 Login SignupGATES 70395 HYD HOSE
Tap to view 1 more
$2349
Limited availability at this price!
In Stock
Get it by Wednesday, Dec 31
GATES 70395 Part Description
Manufacturer
Product Description
M2T MegaFlex 2-Wire Braid Hose - SAE 100R16
Features & Benefits
- For use with GlobalSpiral Couplings [G20 Series], GlobalSpiral Plus Couplings [G22 Series], MegaCrimp Couplings [G25 Series], Stainless Steel Braid Couplings [G17 Series] and Stainless Steel Spiral Couplings [G18 Series]
- Provides bend radius up to 1/3 of the SAE specification and greater flexibility for easier routing
- Tested to industry-leading 600,000 impulse cycles
- XtraTuff hose lasts up to 25 times longer than standard hose
- MegaTuff hose lasts up to 300 times longer than standard hose during hose-to-hose and hose-to-metal abrasion tests per ISO 6945 and offers superior ozone and weathering resistance
- Meets Flame Resistance Acceptance Designation MSHA 2G
- Temperature Range: -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C)
GATES 70395 Specifications
Product Attributes
| Product Type | M2T MegaFlex 2-Wire Braid Hose - SAE 100R16 |
| Industrial Description | 16M2TXREEL |
| Type | Hydraulic Hose |
| Hose Pressure Description | High Pressure |
| Maximum Working Pressure | 2500 PS |
| Burst Pressure | 10000 PS |
| Temperature Rating | -40 Deg. F to +212 Deg. F (-40 Deg. C to +100 Deg. C) |
| Length | 165 FT |
| Dash Size | 16 |
| Inside Diameter | 1 IN |
| Outside Diameter | 1.39 IN |
| Bend Radius | 4.5 IN |
| Tube Description | Black, Oil-Resistant, Synthetic Rubber |
| Hose Material | Nitrile - Type C |
| Reinforcement Material | Two Braids, High-Tensile Steel Wire |
| Cover Material | Synthetic Rubber - Modified Nitrile - Type C2 - Color Coded Layline |
| Cover Type | Type C2 - Flame, Oil, Abrasion & Weather Resistant |
| Cover Color | Black |
| Coupling Recommendation | GlobalSpiral, MegaCrimp, Stainless Steel B |
| SAE Standard | 100R16 |
| EN Standard | 857 2SC, 853 2SN |
| ISO Standard | 11237 2SC R16, 1436 2SN R2 |
Additional Information
| Harmonized Tariff Code (Schedule B) | 4009210000 |
| Country of Origin (Primary) | US |
| UPC | 00072053319026 |
| VMRS Code | 059032029 |
| UNSPSC | 40142020 |
GATES 70395 Part Interchanges
| Brand | Part Number |
|---|---|
| Aeroquip | FC310-16, FC310-16RL |
| Parker | 431-16, 431-16-BX, 431-16-RL |
| Dayco | 010266A, 011466, 11466 |
| Weatherhead | H24516250R, H28016250R, H29016250R |
| Goodyear | GR16-16X250, GR16-16X250RL, GR16-16X50, GR16-16X50BX, GR16SC16X250 |
| NAPA | 70395 |
