GATES part description

Product Description

Super HC Narrow Section Wrapped V-Belt

Application Summary

Gravely, Starter Gen., , Belt

Features & Benefits

  • Up to 300 percent capacity increase over classical belts
  • Proprietary Flex-Weave cover is a patented fabric construction, providing extended protection to the belt core from oil, contaminants and heat for longer belt life
  • Flex-bonded cords are strongly forged to the belt body, resulting in equal load distribution, resistance to fatigue and shock loads and the absorption of bending stress without cord deterioration
  • Belt Edge is machined for even pulley groove contact resulting in smoother running, less slip and wear
  • Meets RMA oil and heat resistant standards and static conductivity requirements
  • Temperature Range: -22 Deg. F to +140 Deg. F (-30 Deg. C to +60 Deg. C)
  • NOTE: Available in 3V, 5V, and 8V cross-sections as well as Super HC PowerBand joined V-belts

Product Attributes

Type Narrow Section Wrapped V-Belt
Cross Section Designation 3V
Strand Quantity 1
Top Width .38 in
Outside Circumference 40 in
Construction Wrapped
9837 No
Belt Material Neoprene
Cord Material Polyester
Top Width 10 mm
Outside Circumference 1016 mm

Additional Information

Harmonized Tariff Code (Schedule B) 4010323000
Country of Origin (Primary) MX
UPC 00072053267488
VMRS Code 065005003
UNSPSC 26111801
