(888) 312-8812 Login SignupGATES 32356 Green Stripe Silicone Hose Clamp
No Stock Available
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
We may have similar parts for sale. Search Alternatives >
GATES 32356 Part Description
Manufacturer
Product Description
Green Stripe Silicone Hose Clamp
Features & Benefits
- 300 series stainless steel band, screw and housing resist corrosion
- Four-piece construction and 100 percent mechanical interlock for added strength and torque capability
- Combination 5/16 in. hexagon with deep slot screw head makes installation easy - tightens with a screwdriver, nut driver or socket wrench
- Wide 9/16 in. band gives 12-1/2 percent more compression than 1/2 in. band
- One-piece band and liner
- Inner-liner band eliminates hose cover extrusion
GATES 32356 Specifications
Product Attributes
| Adjustment Type | Silicone Hose Clamp |
| Hose Clamp Size | 56 |
| Hose Minimum Inside Diameter | 3.25 IN |
| Hose Maximum Inside Diameter | 3.5 IN |
| Minimum Clamping Length | 3.0625 IN |
| Maximum Clamping Length | 4 IN |
| Band Width | .5625 IN |
| Screw Type | .3125 in. Deep Slot Hex-Head |
| Recommended Torque | 30-40 PPI |
| Maximum Torque | 60 IA |
| Material | Stainless Steel |
| Housing Material | Stainless Steel |
| Band Width | 14 MM |
Additional Information
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 7326908688 |
| UPC | 00072053022117 |
| VMRS Code | 053008020 |
| UNSPSC | 31162900 |
GATES 32356 Part Interchanges
| Brand | Part Number |
|---|---|
| Velvac | 022156 |
| ACDelco | 32356C |
| Continental Belt | 51256 |
| Ideal Tridon | 6556790, 6556E51, 6756M, 6756M51 |
| Ideal Hy-Gear | 5356 |
GATES 32356 Cross References
We have 1 alternatives for the 32356 by GATES:
